LUBRICATION PROCEDURE AND CHARTS OPERATOR MANUAL 500E2
5-14 Published 07-26-2019 Control # 111-06
Item Description
1 Boom Nose Pins, Clips
2 Wire Rope
3
All Hardware, Clips, Pins, Hose Connections
not painted O/R Pins, Clips
4 Pivot Shaft
5 Hoist Plumbing Connections
6 Mirror Mounting Hardware
7 O/R Hose Connections
8 O/R Pins, Clips
9 Power Train Hardware
10
Valve Bank, Hose Connections Inside
Turntable
11 Entire underside of unit
12 Hook Block/Downhaul Weight
13 Turntable Bearing Fasteners
14 Pins, Clips for Jib (Not Shown)
15 Hanger Hardware for Jib (Not Shown)
