500E2 OPERATOR MANUAL MAINTENANCE CHECKLIST
6
National Crane Published 07-26-2019 Control # 111-06 6-1
SECTION 6
MAINTENANCE CHECKLIST
SECTION CONTENTS
Crane Inspection And Maintenance . . . . . . . . . . . 6-1
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Daily Inspections. . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Weekly Inspections . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Monthly Inspections . . . . . . . . . . . . . . . . . . . . . . . 6-2
Periodic/Annual Inspection . . . . . . . . . . . . . . . . . . 6-3
Special Boom Inspection . . . . . . . . . . . . . . . . . . . 6-3
Stability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Hoist Cable Inspection and Maintenance. . . . . . . 6-3
Keeping Records . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Environmental Conditions . . . . . . . . . . . . . . . . . . . 6-4
Dynamic Shock Loads . . . . . . . . . . . . . . . . . . . . . 6-4
Precautions and Recommendations During
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Wire Rope Replacement. . . . . . . . . . . . . . . . . . . . 6-5
Care of Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Rope Construction . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Crane Adjustments and Repairs . . . . . . . . . . . . . . 6-6
Jib Jack Service and Maintenance . . . . . . . . . . . . 6-6
Adding Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Changing Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Rust Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Oil Cooler Service and Maintenance (Optional) . . 6-7
Jib Load Limiting Device . . . . . . . . . . . . . . . . . . . . 6-7
Single Character Display . . . . . . . . . . . . . . . . . . . . 6-7
Hydraulic System Trouble Diagnosis . . . . . . . . . . 6-8
Jib Jack Troubleshooting . . . . . . . . . . . . . . . . . . . 6-11
Tire Load And Inflation Table. . . . . . . . . . . . . . . . 6-12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Hydraulic Pump . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Hydraulic System. . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
HCA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Hoist Speed and Pull . . . . . . . . . . . . . . . . . . . . . . 6-15
Crane Operating Speeds . . . . . . . . . . . . . . . . . . . 6-16
CRANE INSPECTION AND MAINTENANCE
A regular schedule of inspection and maintenance is
essential to keep your unit in peak operating efficiency.
Operators or service personnel responsible for the care of
the unit must be completely familiar with the type and
frequency of inspections and maintenance operations. The
following pages outline the inspections and maintenance
required to keep the crane in proper operating condition.
Refer to the Service Manual for complete instructions on
preforming maintenance on this crane.
Inspection
The following pages list inspections which are to be
conducted on your unit to help assure its operating properly
and safely. Check all items listed at the frequency listed and
make necessary repairs prior to operating. Refer to the
Service Manual when installing missing or loose fasteners.
Should a defect be found, a determination must be made as
to whether the deficiency is a safety hazard or though not yet
a safety hazard, needs to be monitored in the monthly
inspections.
The inspections are separated into the following frequency
classifications:
• Daily inspections — These items should be visually
inspected each day by the operator prior to using
the unit.
• Weekly inspections — These items should be
visually inspected weekly by the operator.
• Monthly inspections — These inspections are to be
performed monthly by the personnel responsible for
maintenance and service of the crane.
• Periodic inspections — This inspection is a
thorough inspection conducted at least every three
months and includes all items listed under Daily,
Weekly, and Monthly inspection in addition to those
items listed under periodic inspection. Federal Laws
through OSHA and ANSI B30.5 require that dated
and signed records of these periodic inspections be
kept. A crane inspection log book is available from
National Crane to assist you in keeping records.
