500E2 OPERATOR MANUAL SET-UP
4
National Crane Published 07-26-2019 Control # 111-06 4-9
A Stop Pin B Jib Swing Pin C1 Jib Deployment
C2 Jib Deployment D Stow Loop F Load Line Attachment Point
Jib in Stow Position
JIb in Operating position
A Stow C2 Jib Deployment
B Jib Swing D Stow Loop
C Swing Around E Extension
Retaining
C1 Jib Deployment F Load Line
Attachment
Point
