Manitowoc P Series User Manual

2-5
Section 2 Installation Instructions
WATER SUPPLY AND DRAIN LINE SIZING/CONNECTIONS
CAUTION
Plumbing must conform to state and local codes.
Location
Water
Temperature
Water
Pressure
Ice Machine
Fitting
Tubing Size Up to Ice
Machine Fitting
Ice Making
Water Inlet
33°F (0.6°C) Min.
90°F (32.2°C) Max.
20 psi (137.9 kPA) Min.
80 psi (551.5 kPA) Max.
3/8” Female Pipe
Thread
3/8” (9.5 mm)
minimum inside
diameter
Ice Making
Water Drain
--- ---
1/2” Female Pipe
Thread
1/2” (12.7 mm)
minimum inside
diameter
Bin Drain
--- ---
3/4” Female Pipe
Thread
3/4” (19.1 mm)
minimum inside
diameter

Manitowoc P Series Specifications

General

Brand	Manitowoc
Model	P Series
Category	Ice Maker
Language	English
