ICE/OFF/CLEAN TOGGLE SWITCH
Function
This switch is used to place the ice machine in
ICE, OFF or CLEAN mode of operation.
Specifications
Double-pole, double-throw switch. The switch is
connected into a varying low D.C. voltage circuit.
Check Procedure
NOTE: Because of a wide variation in D.C.
voltage, it is not recommended that a voltmeter be
used to check toggle switch operation.
1. Inspect the toggle switch for correct wiring.
2. Isolate the toggle switch by disconnecting all
wires from the switch, or by disconnecting the
Molex connector and removing wire #69 from
the toggle switch.
3. Check across the toggle switch terminals using
a calibrated ohmmeter. Note where the wire
numbers are connected to the switch terminals,
or refer to the wiring diagram to take proper
readings.
Switch Setting Terminals Ohm Reading
66-62 Open
ICE 67-68 Closed
67-69 Open
66-62 Closed
CLEAN 67-68 Open
67-69 Closed
66-62 Open
OFF 67-68 Open
67-69 Open
4. Replace the toggle switch if ohm readings do
not match all three-switch settings.
HARVEST HEATER ELEMENT
Function
Warms the evaporator in the harvest cycle,
allowing the ice to release.
Specifications
Model Volt Amp Ohm
Upper 115 9.4 to 11.5 10.4 to 12.1
Lower 115 5.1 to 6.2 19.3 to 22.5
*Listed ohm values are at room temperature.
Check Procedure
1. Cycle the ice machine into a harvest sequence.
2. Attach an amp probe to one lead of the harvest
heater element and read amp draw. See
Specifications (above) for amp/ohm values.
Results of Check Action
Amperage
and ohm value
within specifications
Element is OK
No Amperage or
continuity
See Harvest Heater
Thermostat on next
page.
Amperage and/or
Ohm value not
within specifications
Replace the element
Replacement Procedure.
1. Remove evaporator assembly from ice
machine (see page 6-7).
2. Remove clips securing heater element to
evaporator tubing.
3. Align replacement heater element with
evaporator tubing.
4. Secure element to evaporator tubing with
clips.
5. Re-install evaporator assembly.
