Section 4 Maintenance
4-3
Removal of Parts
Overview of Parts Removal
SV1664G
UPPER
AGITATOR
AUGER BEARING
SV1666G
ICE
DEFLECTOR
LOWER
AGITATOR
AUGER BEARING
LOWER
DELIVERY
AUGER BEARING
DELIVERY
AUGER
AGITATOR
AUGER
UPPER
DOOR
SUPPORT
LOWER
DOOR
SUPPORT
FALSE
BOTTOM
UPPER DOOR
RETAINER
