Section 3 Dispenser Operation
3-1
Section 3
Dispenser Operation
Method of Operation (All Models)
When ice is required, the customer or attendant
presses the ice delivery push button switch. This
action activates a relay, which is located in the
control box enclosure. The relay energizes the
dispenser motor.
The dispenser motor is direct-coupled to a right
angle gearbox. This gearbox drives a toothed
positive-displacement belt, the dispensing auger,
and the agitating auger.
Auger Revolutions per Minute
Dispensing Auger 35
Agitator Auger 17
Rate of Delivery
Model Rate of Delivery*
Q290 0.50 - 1.3 oz/sec (15 - 38 g/sec)
Q310
Q330
Q340
0.85 - 3.7 oz/sec (24 - 105 g/sec)
*Depending on cube size and quantity of ice in bin.
Warning
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been, misused,
abused, neglected, damaged, or altered/modified from
that of original manufactured specifications.
