Section 2 Installation Instructions
2-5
Water Service/Drains
WATER CONNECTIONS
Local water conditions may require treatment of the
water to inhibit scale formation, filter sediment, and
remove chlorine odor and taste.
Follow these guidelines to install water inlet lines:
CAUTION
Plumbing must conform to state and local codes.
• Connect to potable water supply only.
• Do not connect to a hot water supply. Be sure all
hot water restrictors installed for other equipment
are working. (Check valves on sink faucets,
dishwashers, etc.)
• If water pressure exceeds the maximum
recommended pressure (90 psig), obtain a water
pressure regulator from your Manitowoc
distributor.
• Install a water shut-off valve at the dispenser.
• Insulate water lines to prevent condensation.
DRAIN CONNECTIONS
Follow these guidelines when installing drain lines to
prevent drain water from backing up into the
dispenser.
CAUTION
Plumbing must conform to state and local codes.
• The dispenser is equipped with a 1/2” F.P.T.
(female pipe thread) fitting at the rear of the
dispenser.
• The dispenser drain must be run separately to
prevent water from other sources from entering
machine.
• Drain lines must be vented to atmosphere.
• Drain lines must have a 1.5 inch (3.75 cm) drop
per 40 inches (1 meter) of run, and must not
create traps.
• The floor drain must be large enough to
accommodate drainage from all drains.
• Insulate the drain line to prevent condensation.
