Q OR J MODEL - DUAL EXPANSION VALVE
Operational Analysis 1 2 3 4
Ice Production
Air-Temperature Entering Condenser____________ Water Temperature Entering Ice Machine_________ Published 24 hour ice production________________ Calculated (actual) ice production________________ NOTE: The ice machine is operating properly if the ice production and ice formation pattern is normal and ice production is within 10% of charted capacity.
Ice Formation Pattern Left Side____________ Right Side___________
Ice formation is
extremely thin on outlet
of one side of
evaporator
-or-
No ice formation on one
side of evaporator
Ice formation is
extremely thin on
outlet of one or both
sides of evaporator
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
Ice formation is
extremely thin on
inlet of one side of
evaporator
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
No ice formation on
entire evaporator
Safety Limits Refer to “Analyzing Safety Limits” to eliminate problems and/or components not listed on this table
Stops on safety limit:
1
Stops on safety limit:
1
Stops on safety limit:
1 or 2
Stops on safety limit:
1
