Manitowoc Q450 User Manual

–106–
Freeze Cycle DISCHARGE pressure _______ ______ _____ 1 minute Middle End into cycle
If discharge pressure is High or Low refer to a freeze cycle high or low discharge pressure prob-
lem checklist to eliminate problems and/or components not listed on this table before proceeding.
Freeze Cycle SUCTION pressure _______ ______ _____ Beginning Middle End
If suction pressure is High or Low refer to a freeze cycle high or low suction pressure problem checklist to eliminate problems and/or components not listed on this table before proceeding.
Suction pressure is
High
Suction pressure is
Low or Normal
Suction pressure is
High
Suction pressure is
High
Harvest Valve Wait 5 minutes into the freeze cycle. Compare temperatures of compressor discharge line and both harvest valve inlets.
One harvest valve inlet
is Hot
-and-
approaches the
temperature of a Hot
compressor discharge
line.
Both harvest valve
inlets are
Cool enough
to hold hand on
-and-
the compressor
discharge line is Hot.
Both harvest valve
inlets are
Cool enough
to hold hand on
-and-
the compressor
discharge line is
Cool enough
to hold hand on.
Both harvest valve
inlets are Cool
enough
to hold hand on
-and-
the compressor
discharge line is Hot
Q OR J MODEL - DUAL EXPANSION VALVE
Operational Analysis 1 2 3 4
