–107–
Discharge Line Temperature Record freeze cycle discharge line temperature at the end of the freeze cycle
_________°F (°C)
Discharge line
emperature
160°F (71.1°C)
or higher
at the end of the freeze
cycle
Discharge line
temperature
160°F (71.1°C)
or higher
at the end of the
freeze cycle
Discharge line
temperature
less than
160°F (71.1°C)
at the end of the
freeze cycle
Discharge line
temperature
160°F (71.1°C)
or higher
at the end of the
freeze cycle
Final Analysis Enter total number of boxes checked in each column
Harvest Valve Leaking Low On Charge
-Or-
TXV Starving
TXV Flooding Compressor
Q OR J MODEL - DUAL EXPANSION VALVE
Operational Analysis 1 2 3 4
