Manitowoc QM30A Service Manual

Section 2 Installation Instructions
2-1
Section 2
Installation Instructions
76.20 cm
(30.00”)
56.74 cm
(22.34”)
50.00 cm
(19.69”)
Ice Making
Water/Bin Drai
n
Ice Making
Water Inle
t
Electrical Inlet
sv1678c
15.24 cm
(6.00”)
Legs
sv1679b
sv1678b
7.24 cm
(2.85”)
7.32 cm
(2.88”)
15.09 cm
(5.94”)
15.73 cm
(
6.19”
)
9.53 cm
(3.75”)
8.51 cm
(
3.35”
)
Levelers
International
ONLY
20.80 cm
(8.19”)
3.33 cm
(1.31”)
