Section 6 Service
6-9
Refrigeration Tubing Schematic
EVAPORATOR
CAP TUBE
COMPRESSOR
HOT GAS
SOLENOID VALVE
CONDENSER
DRIER
sv1598
HEAT
EXCHANGER
