Bin Door

Allows access to the storage bin.

1. Remove top cover.

2. Slide door up until rear pins align with slot in door

tracks.

3. Lift rear door pins out and slide door up until front

door pins align with slot.

4. Lift door out of door track

Align Door Pins With

Track Slots, Then Lift

Door Out Of Track
