Mantis 7940 User Manual

19Contact us at www.mantis.com
Key Qty. Part No. Description T1 1
430070 Trigger Handle Assembly, 4 Cycle Engine, Right
T2
1
430071 Handle Assembly, Left
T3
2
430082 Lower Handle W/Plug
T4
1
430084 Handle Brace Assembly
T7
2
377 Handle Clamp
T8
2
4078 M6 Jam Nut
T9
2
478 Throttle Clip
T10
1
400315 Carry Handle
T11 2
470 Bolt 1/4-20 X 3”
T12
2
400523 Knob, Two Prongs, Female
T13
2
395 Acorn Nut
T14
4
972 1/4-20 Two-Way Lock Nut
T15
2 144-2
1/4-20 X 1.125 Hex Head Cap Screw
T16
2
140 Bolt 1/4-20 X 3/8” Long
T17
1
430058 Mantis Logo Label
T18
2
4079 M6 Internal Lock Washer
T20
1
465 Fender Guard
T21
1
400911 Engine Assembly-25Cc Honda1
T22*
1
468 Drive Shaft
T23
1
466 Worm Gear Housing
T24
1
436 Gasket
T25
1
437A Gear Housing Cover
T26
4
651 #8 Self Tapping Screw
T27
1
423 Roller Bearing
T28
2
425 Worm Bearing Race
Key Qty. Part No. Description T29
1
424 Worm Thrust Bearing
T30
1
422 Worm Shaft
T31 1
426 Worm Disk
T32 1
428 Retaining Ring
T33
1
429 Worm Gear
T34
1
431 Tine Shaft
T35
2
430 Worm Gear Thrust Washer
T36
2
432 Worm Gear Bearing
T37
2
434 Bearing Seal
T38
2
435 Bearing Seal Retainer
T39
1
438RA Tine Assembly, Right
T40
1
438LA Tine Assembly, Left
T41
2
418-1 Tine Retaining Pin
T42
2
430039 Carriage Bolt 1/4-20 X 2.25”
T43
1
430043 Ground Wire Jumper, 4 Cycle Engine
T44
1
400631 Triangle Warning Label (4 Cycly Engine)
T45
1
458 Roller Bearing
T46
1
400010 Transmission Assembly1
T47 1
400131
Clutch Drum
T48 1
400132
Bearing
T49
1
400130 Engine Flange
T50
4
400511 M6 X 12 Flange Bolt
T51 1
910502
10-32 X 3/4” Flange Bolt
T52 1
410158
Kickstand, Stand Assembly
T53 1
410113
Kickstand, Bracket And Hardware
*Also in key T46
Parts List
