Function Schematic
1-Headlight
2-Front turn
signal
(optional)
3-Front
reflector
(optional)
4-Front
mudguard
5-Horn
6-Front fork
7-Rear
taillight
(optional)
8-License
plate light
(optional)
9-Tail light
bracket
(optional)
10-Rear
reflector
(optional)
11-Rear turn
signal
(optional)
12-Rear
mudguard
13-Rear
fork
14-Rear
cushion
15-Rear
shock
16-Motor
17-Front
cushion
18-Charging
port
19Switch
lock
20-Rear disc
brake
21-Chain
22-Rising
wheel
23-Side-support
disconnect
24-Pegs
25-Side
brace
26-Battery
27-Controller
28-Front
disc brake
