Mantis Rawrr User Manual

31
8、Dirt bike (All-Terrain Bike) Parameters Table
Item
Parameter
Basic
Information
Brand
RAWRR
Overall vehicle size
(L*W*H)
1935*795*1200mm
Overall vehicle weight
(including battery weight)
60V/74Kg
72V/76Kg
Maximum load capacity
100Kg
Major
Parameters of
the Dirt Bike
Wheelbase
1290mm
Seat height
850mm
Min. ground clearance
310mm
Max. speed
80Km/h
Max. power
7.5Kw
Full charge range
60V Average Speed
25Km/h≥120km
72V Average Speed
25Km/h≥144km
Protection class
IP65
Body System
Body type
Double-beam forged aluminum alloy
Wheel type
Spoke rim-aluminum alloy 19*1.6
Front tire type
Off-road tire 70/100-19
Rear tire type
Off-road tire 80/100-19
Drivetrain
428H chain 108 links
Front brakes
203mm 4-piston hydraulic disc type
Rear brakes
203mm 4-piston hydraulic disc type
Suspension system
Double-shoulder front fork-travel 220mm
Adjustable external airbag hydraulic shock
absorber-travel 75mm
Motor
Rated power
3800W
Rated torque
10N.m
Rated speed
3800r/min
Climbing angle
100% slope
Cooling method
Natural cooling
Controller
Control scheme
FOC sine wave vector control
Rated input voltage
60V
72V
Rated output current
85AH
71Ah
Operating ambient
temperature
-20~+65
Undervoltage protection
value
49V
59V

Mantis Rawrr Specifications

General

Wheel Size	26 inches
Number of Gears	7-Speed
Brake Type	Hydraulic Disc
Suspension	Front Suspension Fork
Category	Electric Bike
Top Speed	28 mph
Range	40 miles
Brakes	Hydraulic Disc Brakes
Tires	26" x 4" Fat Tires
Frame Material	Aluminum
