3、Quick Installation Guide
DO NOT ASSEMBLE, UNPACK, OR PACK THIS DIRT BIKE
(ALL-TERRAIN BIKE) ALONE. TEAMWORK IS REQUIRED.
Mounting Handlebars
1 、 Place the headlight bracket on the
upper coupling plate, align the four 4
holes, and snap the clamp nut in the slot
in front of the headlight bracket.
2、 Put the handlebar on the headlight
bracket, align the holes, and lock the 4
screws with a 5# Allen wrench.
Note: 4 screws should be added with
bullet spacers.
Handlebars Adjustment
1 、 Loosen 2 screws with a 3#
Allen wrench and rotate the
meter at a suitable angle.
2 、 Loosen 4 screws with 5#
hexagonal wrench to adjust the
handle angle.
Note: Do not lose the screw spring
spacer.
