A
Power operation button (X)
Used to turn the power on/off (standby). (v p. 28)
B
Illumination
Lit when the power is turned on. The brightness of the illumination can
be changed by pressing DIMMER.
C
METER ON/OFF button
Turns the level meter display and meter lighting on or off. (v p. 29)
D
Level meter
Displays the level of the signal input through channel 1. This can be
turned off by pressing METER ON/OFF.
E
Protection circuit indicator
This blinks when the protection circuit has operated. (v p. 32)
F
DIMMER button
Press this button to change the brightness of the illumination.
(v p. 30)
