[8-channel heigh speakes]
Settings AUDIO OUT connectors
Height
Sp
Dolby Sp NOTE Front Layout
Middle
Layout
Rear Layout HEIGHT 1 HEIGHT 2 HEIGHT 3 HEIGHT 4
8ch None
Front Height &
Center Height
Top Middle &
Top Surround
Rear Height Front Height Rear Height Top Middle
L: Top
Surround
R: Center
Height
6ch 2ch
Front Height &
Center Height
Surround
Dolby & Top
Surround
Rear Height Front Height Rear Height
Surround
Dolby
L: Top
Surround
R: Center
Height
z1
This can be selected when using Surround Back speakers.
z2
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup
in place of Surround Height speakers.
z3
Use 2 sets of Height speakers in the appropriate sound modes for Dolby Atmos, DTS:X or Auro-3D playback.
Use the Front Height and Rear Height speakers for Dolby Atmos playback.
Use the Front Height, Surround Height and Rear Height speakers for DTS:X playback.
Use the Front Height and Surround Height speakers for Auro-3D playback.
