L
USB port (POWER SUPPLY)
Can be used to power streaming media players, etc.
M
AC inlet (AC IN)
Used to connect the power cord. (v p. 85)
N
SIGNAL GND terminal
Used to connect a ground wire for the turntable. (v p. 74)
O
UNBALANCED RCA PRE OUT connectors
Used to connect a power amp with UNBALANCED RCA input
connectors. (v p. 45)
P
BALANCED XLR PRE OUT connectors
Used to connect a power amp with BALANCED XLR input connectors.
(v p. 43)
NOTE
0
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
