Connecting 7.1-channel speakers
o
Example layout when using surround back
speakers
This 7.1-channel surround system is basic 7.1-channel system.
(Adding surround back speakers to basic 5.1-channel system)
For each speaker connection, refer to “Connecting a power
amp” (v p. 43).
0
Set “Floor” to “5ch & SB” in the menu when connecting in this configuration.
(v p. 216)
o
Example layout when using front wide
speakers
This 7.1-channel surround system is the same as a basic 5.1-channel
system but with front wide speakers.
For each speaker connection, refer to “Connecting a power
amp” (v p. 43).
0
Set “Floor” to “5ch & FW” in the menu when connecting in this configuration.
(v p. 216)
