Marantz AV560 - Page 29

47
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R698 4822 051 30472 CHIP 4.7kΩ ±5% 1/16W NN05472610
R699 4822 051 30104 CHIP 100kΩ ±5% 1/16W NN05104610
P604-SEMICONDUCTORS
DG01 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
DG02 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
DG03 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
DQ01 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
DR01 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DR02 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D601 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
QC01
4822 209 17155 IC NJM2068M HC10102090
QC11
QC12 4822 209 14869 IC NJU7311AM
2X6 1X2 ANALOG SW
HC10151090
QD01 IC AD1855 DAC 24BIT 96kHz HC10013840
QD51 IC BA033FP
3.3V 1A PD=1W VD=0.3V
HC96J33210
QG01 IC TC9459F ELE-VOLUME HC10449050
QG02 IC TC9459F ELE-VOLUME HC10449050
QG03 IC TC9459F ELE-VOLUME HC10449050
QG04 4822 209 91175 IC NJM2114M OP AMP HC10175090
QG05 4822 209 17155 IC NJM2068M HC10102090
QG06 4822 209 17155 IC NJM2068M HC10102090
QG07
4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QG12
QG13
4822 130 63211 DIG. TRS. BA10004000
QG16 DTA114TS UN4115 10k
QG17 IC 74HC4094BT HC809449R0
QG18 4822 130 63211 DIG. TRS.
DTA114TS UN4115 10k
BA10004000
QG19 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
QG20 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
QH01 4822 209 17155 IC NJM2068M HC10102090
QH02 4822 209 17155 IC NJM2068M HC10102090
QJ01 4822 209 17155 IC NJM2068M HC10102090
QJ02 4822 209 17155 IC NJM2068M HC10102090
QK01 4822 209 14615 IC NJM2115M HC10172090
QK02 4822 209 14615 IC NJM2115M HC10172090
QK04 IC AK4526
2CH.ADC & 6CH.DAC
HC10022480
QQ01 IC NJM4558MD HC10035090
QQ02 IC TC9459F ELE-VOLUME HC10449050
QQ03 IC NJM4558MD HC10035090
QQ04 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QQ05 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QR01 IC CS8414
DINTERFACE RECEIVER
HC10004880
QR02 IC TC74HC151AF HC715100Z0
QR04 4822 209 30426 IC 74HC00 CMOS HC700000Z0
QR06 IC 74HC125 HC712500B0
QR07 IC 74HCU04COMS HC700400Z0
QR08 4822 209 90909 IC TC7W74FU HC10400050
QS01
IC NJM4558MD HC10035090
QS07
QS08 4822 209 32552 IC LC78211 HC10308030
QS09 4822 209 32552 IC LC78211 HC10308030
QS10 IC NJM4558MD HC10035090
QS11 IC NJM4558MD HC10035090
QS12 4822 209 32554 IC LC78213 HC10310030
QS13 IC NJM4558MD HC10035090
Q601 IC YSS912
DTS AC-3 DECODER
HC10014640
Q602 IC TC7W53FU
LMOSLOGIC AMPX
HC007105K0
Q604 IC 1M SRAM 8X128K HC10088000
Q691 MICROPROCESSOR
µPD78018FGC-557-AB8
HU309JN50F
Q692 4822 209 14872 IC 74HC541 SOP HC754100R0
P604-MISCELLANEOUS
JG03 JACK 33FE-BT-VK-N 33PIN YJ07020660
JR01 TERMINAL 2L2P FS NI RF DIG YT02021460
JR02 4822 218 11487 OPTICAL RECIVER GP1F32R YJ15000150
JS01 4822 265 10748 TERMINAL 14X14 RA 2L6P YT02060460
JS02 4822 265 10748 TERMINAL 14X14 RA 2L6P YT02060460
JS03 4822 265 10748 TERMINAL 14X14 RA 2L6P YT02060460
JS06 JACK 23FE-BT-VK-N 23PIN YJ07020560
JS07 JACK 15FE-BT-VK-N 15PIN YJ07020480
LD01
4822 526 10584 FERRITE CORE FC90090010
LD03 ZBF503D-00TA
LD51
4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LD55
LD57 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LD58 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LG63 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LG64 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LK01
4822 526 10584 FERRITE CORE FC90090010
LK03 ZBF503D-00TA
LR02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LS01 4822 280 20501 RELAY MR62-24SR 24V LY20240410
L601 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L680
4822 157 10884 EMI FILTER BLM11A221S FN31000010
L687
L689
4822 157 10884 EMI FILTER BLM11A221S FN31000010
L699
X601 4822 242 10851 CRYSTAL 12.288MHz AT-49 JX12013260
X691 SERAMIC VIB.
CST10.0MTW-TF01 10.0MHz
FQ01005010
P804-POWER SUPPLY
CIRCUIT BOARD
P804-CAPACITORS
C801 4822 122 30103 CER. 0.022µF +80%-20% 50V DK18223310
C802 4822 124 22243 ELECT. 6800µF 16V RA2 OA68801620
C804 4822 122 30103 CER. 0.022µF +80%-20% 50V DK18223310
C805 4822 122 30103 CER. 0.022µF +80%-20% 50V DK18223310
C806 4822 124 22695 ELECT. 2200µF M 35V RA-2 OA22803520
C807 4822 124 22695 ELECT. 2200µF M 35V RA-2 OA22803520
C808 4822 124 21899 ELECT 4.7µF 25V EJ47502510
C809 4822 124 23053 ELECT 1µF 50V EJ10505010
C820 4822 124 41134 ELECT 10µF 63V EA10606310
C823 4822 124 22571 ELECT. 10µF 50V M RA-2 OA10605020
C833 4822 122 31956 CER. 0.001µF ±10% AC400V DK16102840
C907 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
