Marantz AV560 - Page 30

48
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P804-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C901-C906
ELECTROLYTIC CAPACITOR
±20% :C803 C811 C813 C815
C181 C819 C822
PLASTIC FILM CAPACITOR
±5% 50V :
C810 C812 C814 C821 C32
P804-RESISTORS
RF32 JUMPER 75060501P0
RF41 VARIABLE 100k B X4 WITH T RG01040160
RF42 VARIABLE 100k B X4 WITH T RG01040160
R809 2.2MΩ 1/2W RC10225820
P804-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :R801 R802
R804-R808 R810-R812
R814-R816 R901-R911
P804-SEMICONDUCTORS
D801 4822 130 83067 DIODE D3SB 20
V=200V IO=3.0A
HE20020290
D802 4822 130 33057 DIODE S2VB20-4009F05
2A 200V
HE20011290
D803
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D809
D810 4822 130 81659 ZENER DIODE 27V
ZENER EQUIVALENT
HD32701000
D811 4822 130 10667 ZENER DIODE 4.7V
ZENER EQUIVALENT
HD30471000
D812 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D813
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
D815 30V 0.1A
D816
4822 130 82421 DIODE 1D3 1A 200V HD20002710
D819
D901 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D902 JUMPER 75060501P0
D903 JUMPER 75060501P0
D904 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D905 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D911 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D921 4822 130 82421 DIODE 1D3 1A 200V HD20002710
Q801 4822 209 31631 IC NJM7805FA +5V 1A HC38905090
Q802 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q803 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
Q804 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q805 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
Q806 4822 209 83317 IC NJM7815FA +15V 1A HC38915090
Q807 4822 209 31864 IC NJM7915FA-15V 1A HC39915090
Q808 4822 209 31631 IC NJM7805FA +5V 1A HC38905090
Q810 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q811 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q812 4822 209 31631 IC NJM7805FA +5V 1A HC38905090
Q813 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q814 4822 130 42594 DIG. TRS.
DTC144ES UN4211 47k 47k
BA20002000
Q901 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q902 4822 130 42949 TRS. 2SA970 GR OR BL HT109702A0
Q903 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q904 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q905 4822 130 42682 DIG. TRS.
DTA144ES UN4113 47k 47k
BA10002000
Q906 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
P804-MISCELLANEOUS
F802 4822 252 11129 FUSE 2.5A 125V FBT FS10250350
J802 JACK 2P AC OUTLET YJ04002040
J902 TERMINAL AUDIO OUT YT02060500
L801 4822 280 70354 RELAY VB 24MBU-510
5A 240VAC
LY20240310
L802 4822 280 70354 RELAY VB 24MBU-510
5A 240VAC
LY20240310
L803 4822 280 20517 RELAY VS24MB
UL CSA SEMKO
LY10240190
L851 4822 157 70419 LF-4D-102 FN01020020
L901 4822 280 20501 RELAY MR62-24SR 24V LY20240410
L911 4822 280 20501 RELAY MR62-24SR 24V LY20240410
L921 4822 280 20501 RELAY MR62-24SR 24V LY20240410
PF04-TONE CONTROL
CIRCUIT BOARD
PF04-CAPACITORS
CF01 4822 124 21894 ELECT 10µF 16V EJ10601610
CF02 4822 124 21894 ELECT 10µF 16V EJ10601610
CF13 5322 122 32072 CER. 33pF ±5% 50V BLK DD15330300
CF14 5322 122 32072 CER. 33pF ±5% 50V BLK DD15330300
CF15 4822 124 90358 ELECT. 22µF M 16V RA-2 OA22601620
CF16 4822 124 90358 ELECT. 22µF M 16V RA-2 OA22601620
CF21 4822 124 21894 ELECT 10µF 16V EJ10601610
CF27 5322 122 32072 CER. 33pF ±5% 50V BLK DD15330300
CF28 4822 124 90358 ELECT. 22µF M 16V RA-2 OA22601620
CF35 5322 122 32072 CER. 33pF ±5% 50V BLK DD15330300
CF36 4822 124 90358 ELECT. 22µF 16V M RA-2 OA22601620
PF04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CF05-CF08 CF23 CF24
ELECTROLYTIC CAPACITOR
±20% :CF03 CF04 CF22 CF31
CF41 CF42
PLASTIC FILM CAPACITOR
±5% 50V :CF09-CF12 CF25
CF26 CF33 CF34
PF04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RF01-RF16
RF21-RF31 RF34-RF38
PF04-SEMICONDUCTORS
QF01
4822 209 73064 IC IC NJM2068DD HC10053090
QF04
