49
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PL04-S-VIDEO TUNER
CIRCUIT BOARD
PL04-CAPACITORS
CA01 4822 125 50384 TRIM. 20pF VCT51E CT12000200
CA02 4822 122 40306 CER. 0.047µF +80%-20% 50V DK18473310
CA03 4822 122 31823 CER. 15pF ±5% 50V BLK DD15150300
CA04 4822 121 42466 FILM 390pF 100V ECQ-P DF15391550
CA05 4822 122 31205 CER. 47pF ±5% 50V BLK DD15470300
CA06 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CL47 4822 124 21894 ELECT 10µF 16V EJ10601610
CL49 4822 124 21894 ELECT 10µF 16V EJ10601610
CL51
4822 124 21894 ELECT 10µF 16V EJ10601610
CL62
CL63 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL64 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL68 4822 124 21894 ELECT 10µF 16V EJ10601610
CL70 4822 124 21894 ELECT 10µF 16V EJ10601610
CL71 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL72 5322 122 32143 CER. 22pF ±5% 50V BLK DD15220300
CL73 5322 122 32143 CER. 22pF ±5% 50V BLK DD15220300
CL74 4822 124 23053 ELECT 1µF 50V EJ10505010
CL76 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL77 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL78 4822 124 23053 ELECT 1µF 50V EJ10505010
CL79 4822 124 23053 ELECT 1µF 50V EJ10505010
CL80 4822 126 11591 CER. 24pF ±5% 50V BLK DD15240300
CL81 5322 122 32143 CER. 22pF ±5% 50V DD15220300
CL82 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL83 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
C101 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C102 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C202 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C203 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C204 4822 122 40306 CER. 0.047µF +80%-20% 50V DK18473310
C205 4822 124 21894 ELECT 10µF 16V EJ10601610
C206 4822 122 40306 CER. 0.047µF +80%-20% 50V DK18473310
C207 4822 124 23053 ELECT 1µF 50V EJ10505010
C208 4822 122 40306 CER. 0.047µF +80%-20% 50V DK18473310
C209 4822 124 21894 ELECT 10µF 16V EJ10601610
C211 4822 122 40306 CER. 0.047µF +80%-20% 50V DK18473310
C213 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C216 4822 124 21894 ELECT 10µF 16V EJ10601610
C219 4822 124 21899 ELECT 4.7µF 25V EJ47502510
C220 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C221 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C222 4822 124 23053 ELECT 1µF 50V EJ10505010
C223 4822 124 23054 ELECT 0.47µF 50V EJ47405010
C224 4822 124 40786 ELECT 2.2µF 50V EJ22505010
C225 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C303 4822 124 21894 ELECT 10µF 16V EJ10601610
C304 4822 124 21894 ELECT 10µF 16V EJ10601610
C305 JUMPER 75060501P0
C306 JUMPER 75060501P0
C311 4822 124 21899 ELECT 4.7µF 25V EJ47502510
C312 4822 124 21899 ELECT 4.7µF 25V EJ47502510
C315 JUMPER 75060501P0
C316 JUMPER 75060501P0
C501 4822 122 31205 CER. 47pF ±5% 50V BLK DD15470300
C502 4822 122 31205 CER. 47pF ±5% 50V BLK DD15470300
C503 4822 124 23053 ELECT 1µF 50V EJ10505010
C504 4822 124 41604 ELECT 0.1µF 50V EJ10405010
C505 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C507 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
C508 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
C511 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
PL04-CAPACITORS (COMMON
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C218 C509 C510 CL75 CL90
ELECTROLYTIC CAPACITOR
±20% :C103 C210 C212 C506
CL45 CL66 CL67 CL69
PLASTIC FILM CAPACITOR
±5% 50V :C214 C215 C217
C226 C301 C302
PL04-RESISTORS
RL65
4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
RL68
RL70 JUMPER 75060501P0
R209 4822 100 11352 TRIM. 22kΩ RH0638CJ4R RA02230780
R210 JUMPER 75060501P0
R218 4822 100 11351 TRIM. 10kΩ RA01030780
R219 4822 100 11351 TRIM. 10kΩ RA01030780
R301 JUMPER 75060501P0
R302 JUMPER 75060501P0
R307 JUMPER 75060501P0
R308 JUMPER 75060501P0
PL04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R101 R102
R201-R206 R211-R217
R221-R221 R312 R319-R322
R501-R510 R512-R514 RA01
RA02 RL48 RL51-RL64 RL69
RL72RL77 RL79 RL80
RL83-RL87 RL90
PL04-SEMICONDUCTORS
DA01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA03 4822 125 50416 VARICAP SVC342-L HD40009030
DA04 JUMPER 75060501P0
DL01
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DL03 30V 0.1A
D201 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D202 4822 130 80319 ZENER DIODE 9.1V
ZENER EQUIVALENT
HD30911000
D203 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D204 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QL51 IC BA7625 WITH CLAMP HC10189210
QL52 4822 209 17452 IC BA7626 HC10190210
QL55 4822 130 42715 TRS. 2SA608SP 2SA1048
2SA1309 2SA933S
HT10001000
QL56 4822 130 41947 TRS. 2SC536SP 2SC2458
2SC3311 2SC1740S
HT30001000
QL57 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QL58 4822 130 41947 TRS. 2SC536SP 2SC2458
2SC3311 2SC1740S
HT30001000
QL59 4822 130 42715 TRS. 2SA608SP 2SA1048
2SA1309 2SA933S
HT10001000
QL72 IC 74HC4053 HC705300B0
QL74 IC LC74781 OSD HC10377030
