Marantz AV560 - Page 32

50
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QL75 4822 130 61189 DIG. TRS.
DTC114TS UN4215 10k
BA20004000
QL77 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL78 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL79 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QL80 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL81 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
Q201 IC LA1837 HC10384030
Q202 4822 130 62294 TRS. 2SC1809S P 150MW HT318091P0
Q203 4822 130 42594 DIG. TRS.
DTC144ES UN4213 47k 47k
BA20002000
Q204 4822 130 61227 DIG. TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q501 4822 209 30178 IC LC7218 PLL HC10221030
Q502 4822 130 42121 F.E.T. 2SK30ATM Y1 HF200300B0
Q503 4822 130 41947 TRS. 2SC536SP 2SC2458
2SC3311 2SC1740S
HT30001000
PL04-MISCELLANEOUS
A101 VHF TUNER
FM FRONTEND FE341-A02
AV01202260
FA51 CER. FILTER SFZ450JL3 AM FF10045410
F201 4822 242 70911 CER. FILTER SFF10.7MA8-A FF11070610
F202 4822 242 70665 CER. FILTER SFE10.7MS3-A FF11070620
JL51 4822 265 31302 TERMINAL 3P S TERMINAL YT02030350
JL52 4822 265 31302 TERMINAL 3P S TERMINAL YT02030350
J101 4822 290 81537 TERMINAL YKD31-0426 YT01030080
J501 JACK 23FE-BT-VK-N 23PIN YJ07020560
LA01 4822 157 63084 ANT COIL MW ANT 280µH LA10295170
LA02 4822 157 70779 OSC. COIL MW OSC LO70013010
LA03 4822 157 53589 CHOKE COIL TL-8 393J LC23960710
LA06 4822 148 81095 I.F.T. COIL AM IFT LI70033510
LL71 4822 157 62922 CHOKE COIL 33µH
LAL02TA330J
LC13333800
L201 4822 157 63904 I.F.T. COIL FM DET
M292BEAS-5968Z
LI70376010
L301 4822 157 71731 M.P.X. COIL 19/38kHz LPF LS10293020
L302 4822 157 71731 M.P.X. COIL 19/38kHz LPF LS10293020
L551
4822 526 10584 FERRITE CORE FC90090010
L555 ZBF503D-00TA
XL73 4822 242 80288 CRYSTAL AT49 14.31818MHz JX14001260
X501 4822 242 72333 CRYSTAL AD0618CTB 7.2MHz JX07001260
PL14-VIDEO CIRCUIT BOARD
PL14-CAPACITORS
CL01
4822 124 21894 ELECT 10µF 16V EJ10601610
CL08
CL09 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL21 CER. 1200pF ±10% 10V DK16122300
CL22 4822 124 23053 ELECT 1µF 50V EJ10505010
CL23 4822 124 23053 ELECT 1µF 50V EJ10505010
CL24 4822 124 23053 ELECT 1µF 50V EJ10505010
CL25 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL26 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL27 4822 126 11591 CER. 24pF ±5% 50V BLK DD15240300
CL28 5322 122 32143 CER. 22pF ±5% 50V BLK DD15220300
CL29 4822 124 90353 ELECT. 100µF 10V M RA-2 OA10701020
CL30 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CL36 5322 122 32143 CER. 22pF ±5% 50V BLK DD15220300
CL37 5322 122 32143 CER. 22pF ±5% 50V BLK DD15220300
PL14-CAPACITORS (COMMON)
ELECTROLYTIC CAPACITOR
±20% :CL10 CL13 CL15
PL14-RESISTORS
RL10 4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
RL11 4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
PL14-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RL01-RL08 RL13
RL16-RL18 RL21-RL23 RL28
RL31 RL33-RL35 RL91 RL92
RL94 RL97 RU94 RU97
PL14-SEMICONDUCTORS
QL01 IC BA7625 WITH CLAMP HC10189210
QL03 4822 130 42715 TRS. 2SA608SP 2SA1048
2SA1309 2SA933S
HT10001000
QL04 4822 130 41947 TRS. 2SC536SP 2SC2458
2SC3311 2SC1740S
HT30001000
QL05 4822 130 42715 TRS. 2SA608SP 2SA1048
2SA1309 2SA933S
HT10001000
QL06 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QL07 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL08 4822 130 41947 TRS. 2SC536SP 2SC2458
2SC3311 2SC1740S
HT30001000
QL21 IC OSD IC LC74781 HC10377030
QL22 4822 130 60588 DIG. TRS.
DTC114ES UN4211 10k 10k
BA20001000
PL14-MISCELLANEOUS
JL01 4822 265 41264 TERMINAL YKC21-3111 YT02030370
JL02 4822 265 41264 TERMINAL YKC21-3111 YT02030370
JL03 JACK 15PIN FFC15FE-ST-VK-N YJ07020110
JU91 4822 267 41009 TERMINAL RC5 IN OUT YT02020890
JU92 4822 265 10738 TERMINAL 14X14 RA 1LIP YT02010770
LL21 4822 157 62922 CHOKE COIL 33µH
LAL02TA330J
LC13333800
LL23 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
XL23 4822 242 80288 CRYSTAL AT49 14.31818MHz JX14001260
PL24-AUX INPUT
CIRCUIT BOARD
CL91 4822 124 21894 ELECT 10µF 16V EJ10601610
CL93 4822 124 21894 ELECT 10µF 16V EJ10601610
RL93 4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
RL95 4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
RL96 4822 111 41355 RES. 75Ω ±5% 1/6W GD05750160
JL91 TERMINAL A/V JACK BY04040020
PPS04-OWER SW
CIRCUIT BOARD
C831 4822 122 33276 CER. 0.01µF ±5% DE7150 F DK17103840
F801 FUSE 630MA 250V FBT FS10063350
S831 PUSH SW. POWER
SDDLB1 TV-5
SP01012470
