Marantz DR17 - Page 35

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
R608 9965 000 00596 22.6k 1/4W F GM11422620
R611 4822 116 83227 1k 1/10WF NI01102110
R612 4822 116 83227 1k 1/10W
1/10W
1/10W
F NI01102110
R613 4822 116 83253 1.5k F NI01152110
R614 4822 116 83253 1.5k F NI01152110
R615 9965 000 00597 2.61k 1/10W F NI01262110
R616 9965 000 00597 2.61k 1/10W F NI01262110
R617
4822 117 10145 3.3 1/10W J NH85033110
R620
R621 4822 111 90896 100k 1/10W J NI05104110
R622 4822 111 90896 100k 1/10W J NI05104110
R631 4822 111 91365 470 1/10W F NI01471110
R632 4822 111 91365 470 1/10W F NI01471110
R633 4822 051 30223 22k 1/16W J NN05223610
R634 4822 051 30223 22k 1/16W J NN05223610
R641 4822 051 30223 22k 1/16W J NN05223610
R642 4822 117 13632 100k 1/16W J NN05104610
R643 4822 051 30223 22k 1/16W J NN05223610
R644 4822 051 30223 22k 1/16W J NN05223610
R651
4822 116 60309 2.2 1/4W J NH05022140
R654
R655
33 1/6W J NON CHIP GG05330160
R658
R659 4822 117 10833 10k 1/10W J NI05103110
R660 4822 117 10833 10k 1/10W J NI05103110
R661
4822 111 90893 100 1/10W J NI05101110
R664
R665 4822 111 90896 100k 1/10W J NI05104110
R666 4822 111 90896 100k 1/10W J NI05104110
R801 4822 051 30223 22k 1/16W J NN05223610
R835 4822 111 90967 4.7 1/4W J NF05047140
R836 4822 111 90967 4.7 1/4W J NF05047140
MISCELLANEOUS
JF51 4822 267 41009 RCA PIN JACK 2P YT02020890
JF52 9965 000 00607 HLW16S-2C7 1MM PITCH FFC
CONE.
YJ07012760
JT01 4822 265 11582 1P RCA PIN JACK YT02011000
JT02 4822 267 31369 GP1F32T OPTICAL OUTPUT YJ15000090
JT03 9965 000 00607 HLW16S-2C7 1MM PITCH FFC
CONE.
YJ07012760
J301 4822 218 11487 GP1F32R OPTICAL RECIVER YJ15000150
J311 4822 265 11582 RCA PIN JACK 1P YT02011000
J651 9965 000 00593 RCA PIN JACK 2P
(T6743 BLK/BLK)
YT02021390
LF01 4822 158 60654 FERRITE BEADS FC90030070
LT01 4822 158 60654 FERRITE BEADS FC90030070
LT02 4822 158 60654 FERRITE BEADS FC90030070
LT04 4822 142 60422 PULSE TRANSF.
(TPS247MN-0386AN)
TP41042030
L301 4822 158 60654 FERRITE BEADS FC90030070
L303 4822 158 60654 FERRITE BEADS FC90030070
L311 4822 158 60654 FERRITE BEADS FC90030070
L601 4822 157 53873 CHIP INDUCTER 100UH LU12104010
L602 4822 157 53873 CHIP INDUCTER 100UH LU12104010
L651
FN 4822 158 60654 BLM31A02 CHIP INDUCTOR FC90030070
L651
U1B 4822 158 60654 BLM31A02 CHIP INDUCTOR FC90030070
U1G
L652
FN 4822 158 60654 BLM31A02 CHIP INDUCTOR FC90030070
L652
U1B 4822 158 60654 BLM31A02 CHIP INDUCTOR FC90030070
U1G
L610
4822 158 60654 BLM31A02 CHIP INDUCTOR FC90030070
L614
L901 4822 158 60654 FERRITE BEADS FC90030070
L902 4822 158 60654 FERRITE BEADS FC90030070
SF01 4822 277 21559 SLIDE SW. INT/EXT SS02021150
XF01 9965 000 00608 432kHz (CSB432EB) FQ04323010
PY16-LLM CIRCUIT BOARD
CAPACITORS
CY01 9965 000 00603 ELECT 47 F 10V EG47601050
CY02 4822 126 13837 CER. 0.1 F K CHIP DK96104200
CY03 4822 122 40617 CER. 0.1 F 50V Z DD38104010
CY04 4822 122 33761 CER. 22pF 50V J CHIP DD95220300
CY05 4822 122 33761 CER. 22pF 50V J CHIP DD95220300
CY06 4822 126 13837 CER. 0.1 F K CHIP DK96104200
CY07 4822 122 33761 CER. 22pF 50V J CHIP DD95220300
CY08 4822 122 33761 CER. 22pF 50V J CHIP DD95220300
CY09 4822 126 13837 CER. 0.1 F K CHIP DK96104200
CY10 4822 126 13837 CER. 0.1 F K CHIP DK96104200
CY11 4822 126 13837 CER. 0.1 F K CHIP DK96104200
CY12 9965 000 00603 ELECT 47
F 10V EG47601050
CY13 4822 126 13883 CER. 220pF 50V J CHIP DD95221300
DIODES
DY01 4822 130 80326 LT3D8B RED 3O HI10062320
DY02 4822 130 80326 LT3D8B RED 3O HI10062320
DY03 4822 130 81324 CHIP 1SS302 HZ20018050
DY04 4822 130 81324 CHIP 1SS302 HZ20018050
TRANSI
STORS
QY01 4822 209 16055 TMP87CH74F
MICROPROCESSOR
HU376KT000
QY02 4822 209 90908 TC4W53FU HC10399050
QY03 4822 130 61355 2SC2712 0,Y HX327122A0
QY04 TC74HC74AF HC707405Z0
RESISTORS
RY01 4822 051 30393 39K 1/16W J NN05393610
RY02 4822 116 82487 0 1/16W NN05000610
RY03 4822 116 82487 0 1/16W NN05000610
RY04 4822 051 30101 100 1/16W J NN05101610
RY05 4822 051 30101 100 1/16W J NN05101610
RY06 4822 051 30102 1k 1/16W J NN05102610
RY07 4822 051 30102 1k 1/16W J NN05102610
RY08
4822 051 30472 4.7k 1/16W J NN05472610
RY15
RY16 4822 051 30471 470 1/16W J NN05471610
RY17 4822 051 30103 10k 1/16W J NN05103610
RY18 4822 051 30471 470 1/16W J NN05471610
RY20 4822 117 13632 100k 1/16W J NN05104610
RY21 4822 051 30103 10k 1/16W J NN05103610
RY23 4822
1
17 13632 100k 1/16W J NN05104610
RY24 4822 051 30103 10k 1/16W J NN05103610
RY25 4822 051 30101 100 1/16W J NN05101610
RY26 4822 051 30101 100 1/16W J NN05101610
RY27 4822 051 30101 100 1/16W J NN05101610
MISCELLANEOUS
JY01 9965 000 00604 HLW16R-2C7 1MM PITCH FFC
ANGLE
YJ07013060
SY01
9965 000 00373 TACT SW. SP01013370
SY13
VY01 4822 135 00149 BJ563GK FTD HQ30706410
XY01 4822 242 80349 CERALOCK EF0V8004B0
8MHz
FQ08004030
ZY01 4822 130 11494 PRM6936-V4(IR SENSER) HW10004210
1-39
