Marantz DR17 - Page 36

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
P716-LA1 CIRCUIT BOARD
CAPACITORS
C711 4822 122 31765 CER. 100pF 50V J CHIP DD95101300
C712 4822 122 31765 CER. 100pF 50V J CHIP DD95101300
C713 4822 124 22698 ELECT 47 F 25V M OA47602520
C714 4822 124 22698 ELECT 47 F 25V M OA47602520
C715 5322 126 11578 CER. 1000pF 50V K CHIP DK96102300
C716 5322 126 11578 CER. 1000pF 50V K CHIP DK96102300
C951 4822 122 40617 CER. 0.1
F 50V Z DD38104010
RESISTORS
R711 4822 117 13632 100k 1/16W J NN05104610
R712 4822 117 13632 100k 1/16W J NN05104610
R713 4822 117 13632 100k 1/16W J NN05104610
R714 4822 117 13632 100k 1/16W J NN05104610
R715
4822 116 82487 0 1/6W NN05000610
R718
R723 4822 116 82487 0 1/6W NN05000610
R724 4822 116 82487 0 1/6W NN05000610
MISCELLANEOUS
J701 9965 000 00593 RCA PIN JACK 2P T6743 BLK YT02021390
L701 4822 158 60654 FERRITE BEADS FC90030070
L702 4822 158 60654 FERRITE BEADS FC90030070
P726-LA1CIRCUIT BOARD
CAPACITORS
C721 4822 124 41535 ELECT 100 F 25V OA10702520
C722 4822 124 41535 ELECT 100 F 25V OA10702520
C723 4822 126 11687 CER. 0.1 F Z CHIP DK98104200
C724 4822 126 11687 CER. 0.1 F Z CHIP DK98104200
C731 4822 124 41539 ELECT 47 F 16V M OA47601620
C732 4822 124 41539 ELECT 47 F 16V M OA47601620
C954 4822 122 40617 CER. 0.1
F 50V Z DD38104010
C955 4822 122 40617 CER. 0.1 F 50V Z DD38104010
C956 4822 122 40617 CER. 0.1 F 50V Z DD38104010
TRANSISTOR
Q721 4822 209 91175 FLATPACK NJM2114M HC10175090
RESISTORS
R721 9965 000 00594 RK18112 20K 18KAKU
REC.VOL.
RM02030550
R731
4822 051 30103 10k 1/16W J NN05103610
R734
P816-LPS CIRCUIT BOARD
DIODES
D891 4822 130 82421 1D3 1A/200V HD20002710
D893 4822 130 82421 1D3 1A/200V HD20002710
P916-LHP CIRCUIT BOARD
CAPACITORS
C901 4822 124 12404 ELECT 220
F 16V M OA22701620
C902 4822 126 11687 CER. 0.1 F Z CHIP DK98104200
C903 4822 124 12404 ELECT 220 F 16V M OA22701620
C904 4822 126 11687 CER. 0.1 F Z DK98104200
C911 4822 126 12339 CER. 2200pF K DK96222300
C912 4822 126 12339 CER. 2200pF K DK96222300
C913 4822 124 41535 ELECT 100 F 25V OA10702520
C914 4822 124 41535 ELECT 100 F 25V OA10702520
TRANSISTORS
QN91 4822 130 63844 DIGITAL HN1C03F BA20016050
QN92 4822 130 63844 DIGITAL HN1C03F BA20016050
Q901 4822 209 31378 NJM-4556MB HC10045090
RESISTORS
RN91
4822 051 30222 2.2k 1/16W J NN05222610
RN94
R901 4822 051 30123 12k 1/16W J NN05123610
R902 4822 051 30123 12k 1/16W J NN05123610
R903 4822 051 30273 27k 1/16W J NN05273610
R904 4822 051 30273 27k 1/16W J NN05273610
R905
4822 051 30759 75 1/16W J NN05750610
R908
R910 9965 000 00602 RK09L12B0 10KB H.P. VOL. RM01031170
R911 4822 117 13632 100k 1/16W J NN05104610
R912 4822 117 13632 100k 1/16W J NN05104610
MISCELLANEOUS
J902
FN 4822 267 31692 H.P. JACK HLJ0540-01-430
GRY
YJ01003880
J902
N1B U1B 4822 267 31692 H.P JACK HLJ0540-01-410 BLK YJ01003870
J902
N1G
U1G
4822 267 31692 H.P JACK HLJ0540-01-430
GRY
YJ01003880
L910 USB-4 WITH W901 FC50270040
L815 USB-4 WITH W815 FC50270040
LH01 TFCK-25-15- FERRITE
CORD
FC50250020
1-40
