Marantz DV7001 - Page 71

97
QE01 : MM1623
Pin no. Pin name Function
1 VCC1VCC
28 VCC2 V CC 2 is power supply
for 75Ω driver.
2 CIN Croma signal input
3 MUTE1 Mute select
13 MUTE2 Using of MUTE and
POWER-SAVING.
4 CVBSIN Video signal input
6 Y
IN (Composite video or Y)
Sync tip clamp input
5 YC mix. YC MIX select
7 GND1 GND
15 GND2 GND2 is ground
17 GND2 for 75Ω driver.
19 GND2
22 GND2
Pin no. Pin name Function
8 BIAS Bias
9 I/P Interlace /
Progressive select
10 CYIN Luminance input
The input can select
Sync tip clamp or Bias.
Input signal : Y or G
11 CLP Input clamp select
12 CbIN Component input
14 Cr
IN Input signal : Cb or B
Cr or R
