Marantz DV7001 - Page 72

98
Pin no. Pin name Function
24 S1 S1/S2 select
25 S2
16 Cr
OUT Signal output
18 Cb
OUT
20 CYOUT
21 YOUT
23 CVBSOUT
26 COUT
27 S-DCOUT S1/S2 DC output
1
V
CC1
2
C
IN
3
MUTE1
4
CVBS
IN
5
YC mix.
6
Y
IN
7
GND1
8
BIAS
9
I/P
10
CY
IN
11
CLP
12
Cb
IN
13
MUTE2
14
Cr
IN
28
V
CC2
27
S-DC
OUT
26
C
OUT
25
S1
24
S2
23
CVBS
OUT
22
GND2
21
Y
OUT
20
CY
OUT
19
GND2
18
Cb
OUT
17
GND2
16
Cr
OUT
15
GND
6dB
6dB
6dB
- 6dB
6dB
6dB
6dB
6dB
75Ω
Driver
150kΩ
Bias
150kΩ
Bias
150kΩ
Bias
150kΩ
Bias
Clamp
LPF
S-DC out
S1/S2
6.75MHz
200Ω
LPF
6.75MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
Clamp
Bias
Clamp
75Ω
Driver
75Ω
Driver
75Ω
Driver
75Ω
Driver
75Ω
Driver
QE01 : MM1623
