Marantz MA-9S2 - Page 21

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P501 Q523 00MHT348832A0 00MHT348832A0 TRS. ! 2SC4883 O OR Y
P501 Q524 00MHT348832A0 00MHT348832A0 TRS. ! 2SC4883 O OR Y
P501 Q525 00MHT118592A0 00MHT118592A0 TRS. ! 2SA1859 O OR Y
P501 Q526 00MHT118592A0 00MHT118592A0 TRS. ! 2SA1859 O OR Y
P501 Q527 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P501 Q528 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P501 Q529 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P501 Q530 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P501 R507 00MRA04720780 00MRA04720780 TRIM. RES. 4.7KOHM RH0638CS3R
P501 R508 00MRA04720780 00MRA04720780 TRIM. RES. 4.7KOHM RH0638CS3R
P501 R519 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P501 R520 ns
p
00MGD05683160 RES. 68K OHM +-5% 1/6W
P501 R537 ns
p
00MGD05105160 RES. 1M OHM +-5% 1/6W
P501 R539 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P501 R540 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P501 R541 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P501 R542 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P501 R543 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P501 R544 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P501 R545 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P501 R546 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P501 R547 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R548 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R549 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R550 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R551 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R552 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R553 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R554 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P501 R555 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
P501 R556 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
P501 R557 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
P501 R558 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
MAIN AMP PWB P601
(
00MWG339J601-
)
P601 C301 ns
p
00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 C302 ns
p
00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 C303 ns
p
00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 C304 ns
p
00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 C305 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P601 C308 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P601 C309 ns
p
00MOA47405020 ELECT. CAP. 0.47UF M 50V RA-2
P601 C311 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +-5% FAS
P601 C603 ns
p
00MOA107025Z0 ELECT. CAP. ROS-25V 101M-H4#PE
(
100UF 25V
)
P601 C604 ns
p
00MOA107025Z0 ELECT. CAP. ROS-25V 101M-H4#PE
(
100UF 25V
)
P601 C605 00MOF56681540 00MOF56681540 FILM CAP. FPS-200V-681K
(
680PF 10%
)
P601 C606 00MOF56681540 00MOF56681540 FILM CAP. FPS-200V-681K
(
680PF 10%
)
P601 C607 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +-5% FNS
P601 C608 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +-5% FNS
P601 C609 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +-5% FNS
P601 C610 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +-5% FNS
P601 C611 ns
p
00MOA47708020 ELECT. CAP. 470UF 80V FOR MA9S2
P601 C612 ns
p
00MOA47708020 ELECT. CAP. 470UF 80V FOR MA9S2
P601 C613 ns
p
00MOA47708020 ELECT. CAP. 470UF 80V FOR MA9S2
P601 C614 ns
p
00MOA47708020 ELECT. CAP. 470UF 80V FOR MA9S2
P601 D301 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D302 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D303 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D304 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D305 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D601 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D602 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D603 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D604 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D605 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D606 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D607 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D608 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
29
