NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P601 D609 00MHI10095320 00MHI10095320 L.E.D. LT3K44B GREEN 30MA
P601 D610 00MHI10095320 00MHI10095320 L.E.D. LT3K44B GREEN 30MA
P601 D611 00MHI10095320 00MHI10095320 L.E.D. LT3K44B GREEN 30MA
P601 D612 00MHI10095320 00MHI10095320 L.E.D. LT3K44B GREEN 30MA
P601 D613 00MHD30471000 00MHD30471000 ZENER DIODE 4.7V ZENER EQUIVALENT
P601 D614 00MHD30471000 00MHD30471000 ZENER DIODE 4.7V ZENER EQUIVALENT
P601 D615 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D616 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D617 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 D618 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P601 K011 00MHK135819A0 00MHK135819A0 TRS. KIT 2SA1358 O,2SC3421 O PAIR FOR Q629/Q631
P601 K012 00MHK135819A0 00MHK135819A0 TRS. KIT 2SA1358 O,2SC3421 O PAIR FOR Q630/Q632
P601 L301 00MLY20240310 00MLY20240310 RELAY VB-24MBU-510-UC
P601 L302 00MLY20240310 00MLY20240310 RELAY VB-24MBU-510-UC
P601 Q301 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q302 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q303 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q304 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q305 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q306 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q307 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q308 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q309 00MHC10042050 00MHC10042050 IC IC TA7317P
P601 Q601 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q602 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q603 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q604 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q605 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q606 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q607 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q608 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q609 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q610 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q611 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q612 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q613 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q614 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q615 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q616 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q617 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q618 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q619 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q620 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q621 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q622 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P601 Q623 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q624 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P601 Q625 00MHT113602A0 00MHT113602A0 TRS. 2SA1360 O OR Y
P601 Q626 00MHT113602A0 00MHT113602A0 TRS. 2SA1360 O OR Y
P601 Q627 00MHT334232A0 00MHT334232A0 TRS. 2SC3423 O OR Y
P601 Q628 00MHT334232A0 00MHT334232A0 TRS. 2SC3423 O OR Y
P601 Q629 ns
p
ns
p
TRS. 2SC3421 O,Y 120V,1A PAIR WITH Q631 OF K011
P601 Q630 ns
p
ns
p
TRS. 2SC3421 O,Y 120V,1A PAIR WITH Q632 OF K012
P601 Q631 ns
p
ns
p
TRS. 2SA1358 O,Y 120V 1A PAIR WITH Q629 OF K011
P601 Q632 ns
p
ns
p
TRS. 2SA1358 O,Y 120V 1A PAIR WITH Q630 OF K012
P601 R301 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R302 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R303 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R304 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R305 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R306 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R307 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R308 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R309 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R310 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R311 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
P601 R312 00MGW05001050 00MGW05001050 RES. ! 0.1 OHM J 5W BWR5
