NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P691 D691 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P691 D692 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P691 R691 00MRA02220760 00MRA02220760 TRIM. RES. VAR. RES. 2.2KOHM VERTICAL
P691 R692 00MRA02220760 00MRA02220760 TRIM. RES. VAR. RES. 2.2KOHM VERTICAL
P691 R693 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P691 R694 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P691 R695 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P691 R696 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
POWER SUPPLY PWB P801
(
00MWG339J604-
)
P801 C801 ns
p
00MOA47808020 ELECT. CAP. 4700UF 80V FOR MA9S2
P801 C802 ns
p
00MOA47808020 ELECT. CAP. 4700UF 80V FOR MA9S2
P801 C803 ns
p
00MOA10805020 ELECT. CAP. ELNA RA2 16X25
P801 C804 ns
p
00MOA10805020 ELECT. CAP. ELNA RA2 16X25
P801 C805 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C806 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C807 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C808 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C809 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P801 C903 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P801 C904 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P801 C905 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P801 C906 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P801 C908 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C909 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE
(
220UF 25V
)
P801 C910 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P801 C911 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P801 D801 00MHE10007100 00MHE10007100 DIODE ! KCH30A15
(
CATHODE COMON
)
P801 D802 00MHE10008100 00MHE10008100 DIODE ! KRH30A15
(
ANODE COMON
)
P801 D803 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D804 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D805 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D806 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D807 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D808 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D809 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D810 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D811 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D812 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D813 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D814 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D815 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D816 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D817 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D818 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D819 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D820 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P801 D821 00MHD30012010 00MHD30012010 ZENER DIODE HZ24-2L
P801 D822 00MHD30012010 00MHD30012010 ZENER DIODE HZ24-2L
P801 D823 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D824 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D825 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D826 00MHD20059100 00MHD20059100 DIODE ! 21DQ10
P801 D827 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D828 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D901 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D902 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D903 00MHI10095320 00MHI10095320 L.E.D. LT3K44B GREEN 30MA
P801 D904 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D905 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D906 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D907 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 D908 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
P801 G801 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
P801 G802 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
P801 G803 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
P801 G804 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
P801 G805 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
