Marantz MA-9S2 - Page 25

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P801 L901 00MLY20240470 00MLY20240470 RELAY ED2-24
P801 Q801 00MHT41415100 00MHT41415100 TRS. ! 2SD1415
P801 Q802 00MHT21020100 00MHT21020100 TRS. ! 2SB1020
P801 Q803 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P801 Q804 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P801 Q901 00MHC10111090 00MHC10111090 IC NJM2114D
P801 Q902 00MHC10111090 00MHC10111090 IC NJM2114D
P801 Q903 00MHC10111090 00MHC10111090 IC NJM2114D
P801 Q904 00MHC10111090 00MHC10111090 IC NJM2114D
P801 Q905 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
P801 R803 00MGG05010120 00MGG05010120 RES. ! ERD50FJ1R0P/SPRX1CM12.5A J 1R0
P801 R804 00MGG05010120 00MGG05010120 RES. ! ERD50FJ1R0P/SPRX1CM12.5A J 1R0
P801 R807 00MGG05010140 00MGG05010140 RES. ! 1 OHM +-5% 1/4W
P801 R808 00MGG05010140 00MGG05010140 RES. ! 1 OHM +-5% 1/4W
P801 R809 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R810 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R811 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P801 R812 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P801 R813 00MGG05047160 00MGG05047160 RES. ! 4.7 OHM +-5% 1/6W
P801 R815 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P801 R816 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P801 R817 00MGG05010120 00MGG05010120 RES. ! ERD50FJ1R0P/SPRX1CM12.5A J 1R0
P801 R819 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R820 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R821 ns
p
00MGD05333160 RES. 33K OHM +-5% 1/6W
P801 R822 ns
p
00MGD05333160 RES. 33K OHM +-5% 1/6W
P801 R901 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P801 R902 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P801 R903 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R904 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R905 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R906 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R907 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R908 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R909 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R910 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R911 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R912 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R913 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R914 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R915 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R916 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P801 R917 00MRA02230780 00MRA02230780 TRIM. RES. 22KOHM RH0638CJ4R
P801 R918 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
P801 R919 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
P801 R920 ns
p
00MGD05104160 RES. 100K OHM +-5% 1/6W
P801 R921 ns
p
00MGD05682160 RES. 6.8K OHM +-5% 1/6W
P801 R922 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P801 R923 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P801 R924 ns
p
00MGD05681160 RES. 680 OHM +-5% 1/6W
P801 R925 ns
p
00MGD05151160 RES. 150 OHM +-5% 1/6W
P801 R931 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
AC INLET PWB P851
(
00MWG339J506-
)
P851 C851 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P851 C852 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P851 C853 ns
p
00MOA22703520 ELECT. CAP. 220UF 35V M RA-2
P851 C854 ns
p
00MOA47603520 ELECT. CAP. 47UF M 35V RA-2
P851 C855 ns
p
00MOA22703520 ELECT. CAP. 220UF 35V M RA-2
P851 C856 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P851 D851 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P851 D852 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
P851 D859 ns
p
00MHD20027010 DIODE HSS81TD-E 150V 150MA
P851 F851 F N ns
p
0520100210050 FUSE # 0218015MXP T15A L 250V
P851 F851
/
K1G ns
p
0520100180090 FUSE # 021806.3MXP
(
FUSE 6.3A 250V
)
P851 F851
/
N1G 0520100180090 0520100180090 FUSE # 021806.3MXP
(
FUSE 6.3A 250V
)
P851 F851
/
U1G ns
p
0520100210050 FUSE # 0218015MXP T15A L 250V
P851 G851 00MBF47400020 00MBF47400020 CAP.COMP. 0.47UF+6.8OHM RFD2B474K
33
