Marantz MA-9S2 - Page 26

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P851 L851 F N ns
p
00MTS13521210 TRANSF. # POWER TRANSF. FOR BACKUP 100V
P851 L851
/
K1G ns
p
00MTS13521230 TRANSF. # POWER TRANSF. FOR BACKUP 230V
P851 L851
/
N1G 00MTS13521230 00MTS13521230 TRANSF. # POWER TRANSF. FOR BACKUP 230V
P851 L851
/
U1G ns
p
00MTS13521220 TRANSF. # POWER TRANSF. FOR BACKUP 120V
P851 L852 00MLY10240240 00MLY10240240 RELAY ! VS24MB-NR TV-8 SEMKO LISTED
P851 L853 00MLY10240240 00MLY10240240 RELAY ! VS24MB-NR TV-8 SEMKO LISTED
P851 Q851 00MHT418622A0 00MHT418622A0 TRS. 2SD1862 TV-2 NPN Q,R
P851 R851 00MNQ15022070 00MNQ15022070 ROTOR RES. ! 2.2 OHM 7W W/TEMP.FUSE
P851 R852 00MNQ15022070 00MNQ15022070 ROTOR RES. ! 2.2 OHM 7W W/TEMP.FUSE
P851 R853 00MGA05220010 00MGA05220010 RES. ! 22 OHM +-5% 1W
P851 R854 ns
p
00MGD05332160 RES. 3.3K OHM +-5% 1/6W
P851 R855 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P851 R856 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
POWER SW PWB P871
(
00MWG339J505-
)
P871 C871 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
P871 S871 00MSP01012500 00MSP01012500 PUSH SW ! ESB92S13B TV-5 STROKE=1.5MM
LEVEL ON/OFF SW PWB P941
(
00MWG339J504-
)
P941 S941 00MSP02010960 00MSP02010960 PUSH SW ALPS SUL
LEVEL METER PWB P951
(
00MWG339J507-
)
P951 C951 ns
p
00MOA10505020 ELECT. CAP. 1 UF M 50V RA-2
P951 C952 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P951 C953 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P951 C954 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P951 C956 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P951 C957 ns
p
00MOA10602520 ELECT. CAP. 10 UF M 25V RA-2
P951 D951 00MHI10040080 00MHI10040080 L.E.D. SELU1E10CXM-S BLUE LED
P951 M951 00MIM31050010 00MIM31050010 V.U METER KFM-8A LEVEL METER
P951 Q951 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P951 Q952 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P951 Q953 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
P951 Q954 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
P951 R953 ns
p
00MGD05472160 RES. 4.7K OHM +-5% 1/6W
P951 R955 ns
p
00MGD05681160 RES. 680 OHM +-5% 1/6W
P951 R956 ns
p
00MGD05104160 RES. 100K OHM +-5% 1/6W
P951 R957 ns
p
00MGD05104160 RES. 100K OHM +-5% 1/6W
P951 R958 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
P951 R959 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P951 R960 ns
p
00MGD05223160 RES. 22K OHM +-5% 1/6W
P951 R961 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
L LED PWB P971
(
00MWG339J508-
)
P971 D971 00MHI10040080 00MHI10040080 L.E.D. SELU1E10CXM-S BLUE LED
P971 J971 00MYP07001950 00MYP07001950 PLUG IMSA-1068-05Z042 5P
P971 R971 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
R LED PWB P981
(
00MWG339J509-
)
P981 D981 00MHI10040080 00MHI10040080 L.E.D. SELU1E10CXM-S BLUE LED
P981 J981 00MYP07001950 00MYP07001950 PLUG IMSA-1068-05Z042 5P
P981 R981 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
POSISTOR PWB P991
(
00MWG339J606-
)
P991 R991 00MHP00009230 00MHP00009230 VARISTOR POSISTOR PTH487
(
01BB-120
)
HDAM-SA S2 PWB PH01
(
00MWA339J701-
)
PH01 DH01 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH02 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH03 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 DH04 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PH01 JH01 00MYP07005720 00MYP07005720 PLUG IMSA-6065B-06Z074-PT1
PH01 JH02 00MYP07005710 00MYP07005710 PLUG IMSA-6065B-05Z074-PT1
PH01 QH01 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
PH01 QH02 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH03 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
PH01 QH04 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH05 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PH01 QH06 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
PH01 RH01 ns
p
00MGD05471160 RES. 470 OHM +-5% 1/6W
PH01 RH02 ns
p
00MGD05471160 RES. 470 OHM +-5% 1/6W
PH01 RH03 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH04 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PH01 RH05 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
