Marantz MM7025 Specifications

MM7025
©2010 Marantz America, LLC · www.marantz.com
All specifications, dimensions and weights are subject to change without notice.
D&M Holdings, Marantz, Marantz America, LLC. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors
Being made by dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.
140 Watt x 2-Channel Power Amplifier
Rated power output 140 W/ch, 8 Ω
(from 20 Hz to 20 kHz, two channels
driven): 170 W/ch, 6 Ω
Maximum effecve output power 210 W/ch, 6 Ω
(from 1 kHz, two channels driven):
Output bandwidth (8 Ω load, 0.09 %): 5 Hz – 40 kHz
Frequency response (1 W, 8 Ω): 8 Hz – 100 kHz (±3 dB)
Damping factor: 100
Input sensivity/impedance: 1.2 V / 22 kΩ (UNBALANCED)
2.4 V / 30 kΩ (BALANCED)
Signal-to-noise rao (IHF-A): 105 dB
Voltage amplificaon level: 29 dB
Supply voltage: AC 230 V, 50 Hz
Power consumpon: 330 W
Standby power: 0.2 W
Maximum external dimensions: 440 (W) x 126 (H) x 352 (D) mm
Weight: 10.8 kg
SPECIFICATIONS
Also Available:
MM7055 5-channel Power Amplifier
SYSTEMS
AV7005
7.1 System
AV7005
5.1 System
SR7005
5.1 BiAmp System
AVR L&R Upgrade

Marantz MM7025 Specifications

General

Output level	2.4 mV
Damping factor	100
Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	30000 Ω
Input sensitivity	1.2 mV
Audio output channels	2.0 channels
Peak power per channel	170 W
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.03 %
RMS power output per channel (8 Ohm)	140 W
AC (power) in	Yes
Audio (L/R) in	2
Line inputs (RCA)	1
Speakers connectivity type	XLR
Material	Metal
Cooling type	Passive
Product color	Black
Connectivity technology	Wired
Power consumption (standby)	0.4 W
Power consumption (typical)	220 W

Weight and Dimensions

Depth	350 mm
Width	440 mm
Height	126 mm
Weight	10500 g
