Marantz MM8003 - Page 48

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
AMP1 PWB
(
CUP12071Y
)
AMP1 C101 ns
p
00MOA47505020 ELECT CAP.
4.7UF 50V
CCEA1HH4R7T
AMP1 C201 ns
p
90M-OA000150R ELECT CAP.
22UF 50V
CCEA1HROA220T
AMP1 C202 943133000590S 943133000590S FILM CAP.
330PF/100VDC POLYPROPYLENE
CCMP2A331JA02T
AMP1
C203
90M OA000120R
ELECT CAP
UF V
POS. NO.
AMP1
C203
ns
p
90M
-
OA000120R
ELECT
CAP
.
100
UF
50
V
HCEA1HAHS101T
AMP1 C204 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C205 ns
p
ns
p
CER. CAP.
10PF 50V DC
CCCT1H100DC
AMP1 C206 943133000600S 943133000600S FILM CAP.
3300PF/100VDC POLYPROPYLENE
CCMP2A332JA02T
AMP1 C207 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C208 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C209 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA-2
CCEA1HRA220T
AMP1 C210 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C211 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1
C212
nsp
nsp
FILM CAP
0 01UF 100V J
HCQI1H103JZT
AMP1
C212
nsp
nsp
FILM
CAP
.
0
.
01UF
100V
J
HCQI1H103JZT
AMP1 C213 ns
p
ns
p
CER. CAP.
2200PF 50V KB
CCKT1H222KB
AMP1 C214 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA-2
CCEA1HRA101T
AMP1 C215 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
AMP1 C216 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
AMP1 C301 ns
p
90M-OA000150R ELECT CAP.
22UF 50V
CCEA1HROA220T
AMP1 C302 943133000590S 943133000590S FILM CAP.
330PF/100VDC POLYPROPYLENE
CCMP2A331JA02T
AMP1 C303 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C304 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C305 ns
p
ns
p
CER. CAP.
10PF 50V DC
CCCT1H100DC
p
p
AMP1 C306 943133000600S 943133000600S FILM CAP.
3300PF/100VDC POLYPROPYLENE
CCMP2A332JA02T
AMP1 C307 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C308 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C309 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA-2
CCEA1HRA220T
AMP1 C310 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C311 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C312 ns
p
ns
p
FILM CAP.
0.01UF 100V J
HCQI1H103JZT
AMP1 C313 ns
p
ns
p
CER. CAP.
2200PF 50V KB
CCKT1H222KB
AMP1 C314 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA-2
CCEA1HRA101T
AMP1 C315 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
AMP1 C316 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
AMP1 C401 ns
p
90M-OA000150R ELECT CAP.
22UF 50V
CCEA1HROA220T
AMP1 C402 943133000590S 943133000590S FILM CAP.
330PF/100VDC POLYPROPYLENE
CCMP2A331JA02T
AMP1 C403 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C404 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C405 ns
p
ns
p
CER. CAP.
10PF 50V DC
CCCT1H100DC
AMP1 C406 943133000600S 943133000600S FILM CAP.
3300PF/100VDC POLYPROPYLENE
CCMP2A332JA02T
AMP1 C407 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1
C408
nsp
00MOA10710020
ELECT CAP
100UF 100V RA 2
CCEA2ARA101E
AMP1
C408
nsp
00MOA10710020
ELECT
CAP
.
100UF
100V
RA
-
2
CCEA2ARA101E
AMP1 C409 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA-2
CCEA1HRA220T
AMP1 C410 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C411 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C412 ns
p
ns
p
FILM CAP.
0.01UF 100V J
HCQI1H103JZT
AMP1 C413 ns
p
ns
p
CER. CAP.
2200PF 50V KB
CCKT1H222KB
AMP1 C414 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA-2
CCEA1HRA101T
AMP1 C415 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
AMP1 C416 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
AMP1
C50
1n
sp
90
M-
O
A
000
1
50
R ELE
C
T
C
AP.
22UF 50V
CCEA1HROA220T
C50
sp
90 O 000 50
CC
AMP1 C502 943133000590S 943133000590S FILM CAP.
330PF/100VDC POLYPROPYLENE
CCMP2A331JA02T
AMP1 C503 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C504 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
AMP1 C505 ns
p
ns
p
CER. CAP.
10PF 50V DC
CCCT1H100DC
AMP1 C506 943133000600S 943133000600S FILM CAP.
3300PF/100VDC POLYPROPYLENE
CCMP2A332JA02T
AMP1 C507 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C508 ns
p
00MOA10710020 ELECT CAP.
100UF 100V RA-2
CCEA2ARA101E
AMP1 C509 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA-2
CCEA1HRA220T
AMP1 C510 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C511 ns
p
ns
p
CER. CAP.
47PF/500VDC
CCCT2H470JT
AMP1 C512 ns
p
ns
p
FILM CAP.
0.01UF 100V J
HCQI1H103JZT
AMP1 C513 ns
p
ns
p
CER. CAP.
2200PF 50V KB
CCKT1H222KB
AMP1 C514 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA-2
CCEA1HRA101T
AMP1 C515 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
AMP1 C516 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
AMP1 CN10 ns
p
ns
p
CORD
2P WIRE ASSY 300MM 220MM UL1015
CWZMM8003CN10
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
