Marantz MM8003 - Page 56

P.W.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
POS. NO.
AMP1 R455 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 150 OHM)
CRG2SANJ151RT
AMP1 R456 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1 R457 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1 R458 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1
R459
RES
K OHM / W J CARBON
AMP1
R459
ns
p
ns
p
RES
.
33
K
OHM
1
/
6
W
J
CARBON
CRD20TJ333T
AMP1 R460 ns
p
ns
p
RES.
18 OHM 1/6W J
CRD20TJ180T
AMP1 R461 ns
p
ns
p
RES.
10 OHM 1/6W J CARBON
CRD20TJ100T
AMP1 R462 ns
p
ns
p
RES.
100 OHM 1/6W J CARBON
CRD20TJ101T
AMP1 R463 ns
p
ns
p
RES.
100 OHM 1/6W J CARBON
CRD20TJ101T
AMP1 R464 ns
p
ns
p
RES.
33K OHM 1/6W J CARBON
CRD20TJ333T
AMP1 R465 ns
p
ns
p
RES.
22K OHM 1/6W J CARBON
CRD20TJ223T
AMP1 R501 ns
p
ns
p
RES.
33K OHM 1/6W J CARBON
CRD20TJ333T
AMP1 R502 ns
p
ns
p
RES.
1K OHM 1/6W J CARBON
CRD20TJ102T
AMP1
R503
nsp
nsp
RES
METAL OXIDE FILM(2W 1 5K OHM)
CRG2SANJ152RT
AMP1
R503
nsp
nsp
RES
.
METAL
OXIDE
FILM(2W
1
.
5K
OHM)
CRG2SANJ152RT
AMP1 R504 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 1.5K OHM)
CRG2SANJ152RT
AMP1 R505 ns
p
ns
p
RES.
100 OHM 1/6W J CARBON
CRD20TJ101T
AMP1 R506 ns
p
ns
p
RES.
6.8K OHM 1/6W J CARBON
CRD20TJ682T
AMP1 R507 ns
p
ns
p
RES.
33 OHM 1/6W J CARBON
CRD20TJ330T
AMP1 R508 ns
p
ns
p
RES.
33 OHM 1/6W J CARBON
CRD20TJ330T
AMP1 R509 ns
p
ns
p
RES.
6.8K OHM 1/6W J CARBON
CRD20TJ682T
AMP1 R510 ns
p
ns
p
RES.
470 OHM 1/4W FLAME RETARDANT
CRG14SANCJ471T
AMP1 R511 ns
p
ns
p
RES.
33 OHM 1/6W J CARBON
CRD20TJ330T
AMP1 R512 ns
p
ns
p
RES.
33 OHM 1/6W J CARBON
CRD20TJ330T
p
p
AMP1 R513 ns
p
ns
p
RES.
470 OHM 1/4W FLAME RETARDANT
CRG14SANCJ471T
AMP1 R514 90M-NB000010R 90M-NB000010R RES.
LT20001/6S J LINEAR POSITIVE TEMP
HRT16C1512000JT
AMP1 R515 ns
p
ns
p
RES.
330K OHM 1/6W J CARBON
CRD20TJ334T
AMP1 R516 ns
p
ns
p
RES.
330K OHM 1/6W J CARBON
CRD20TJ334T
AMP1 R517 90M-NB000010R 90M-NB000010R RES.
LT20001/6S J LINEAR POSITIVE TEMP
HRT16C1512000JT
AMP1 R518 ns
p
ns
p
RES.
6.8K OHM 1/6W J CARBON
CRD20TJ682T
AMP1 R519 ns
p
ns
p
RES.
1K 1/4W 5% FRAME
CRG14SANCJ102T
AMP1 R521 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 10 OHM)
CRG2SANJ100RT
AMP1 R522 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 10 OHM)
CRG2SANJ100RT
AMP1 R523 ns
p
ns
p
RES.
100 OHM 1/4W FLAME RETARDANT
CRG14SANCJ101T
AMP1 R524 ns
p
ns
p
RES.
100 OHM 1/4W FLAME RETARDANT
CRG14SANCJ101T
AMP1 R525 ns
p
ns
p
RES.
METAL OXIDE FILM(1W 1K OHM)
CRG1SANJ102RT
AMP1 R526 ns
p
ns
p
RES.
47 OHM 1W J METAL OXIDE FILM
KRG1SANJ470RT
AMP1 R527 ns
p
ns
p
RES.
47 OHM 1W J METAL OXIDE FILM
KRG1SANJ470RT
AMP1 R528 ns
p
ns
p
RES.
METAL OXIDE FILM(1W 220 OHM)
CRG1SANJ221RT
AMP1 R529 ns
p
ns
p
RES.
10 OHM 1W J METAL OXIDE FILM
KRG1SANJ100RT
AMP1 R530 ns
p
ns
p
RES.
10 OHM 1W J METAL OXIDE FILM
KRG1SANJ100RT
AMP1 R531 ns
p
ns
p
RES.
15K OHM 1/6W J CARBON
CRD20TJ153T
AMP1
R532
nsp
nsp
RES
330K OHM 1/6W J CARBON
CRD20TJ334T
AMP1
R532
nsp
nsp
RES
.
330K
OHM
1/6W
J
CARBON
CRD20TJ334T
AMP1 R533 ns
p
ns
p
RES.
22K OHM 1/6W J CARBON
CRD20TJ223T
AMP1 R534 ns
p
ns
p
RES.
150K OHM 1/6W CARBON
CRD20TJ154T
AMP1 R555 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 150 OHM)
CRG2SANJ151RT
AMP1 R556 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1 R557 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1 R558 ns
p
ns
p
RES.
METAL OXIDE FILM(2W 120 OHM)
CRG2SANJ121RT
AMP1 R559 ns
p
ns
p
RES.
33K OHM 1/6W J CARBON
CRD20TJ333T
AMP1 R560 ns
p
ns
p
RES.
18 OHM 1/6W J
CRD20TJ180T
AMP1 R
56
1n
sp
n
sp
RE
S
.
10 OHM 1/6W J CARBON
CRD20TJ100T
56
sp
sp
S
AMP1 R562 ns
p
ns
p
RES.
100 OHM 1/6W J CARBON
CRD20TJ101T
AMP1 R563 ns
p
ns
p
RES.
100 OHM 1/6W J CARBON
CRD20TJ101T
AMP1 R564 ns
p
ns
p
RES.
33K OHM 1/6W J CARBON
CRD20TJ333T
AMP1 R565 ns
p
ns
p
RES.
22K OHM 1/6W J CARBON
CRD20TJ223T
AMP1 RS20 943129000820S 943129000820S RES.
0.1 OHM 5W CEMENT
CRF5EKR10X2
AMP1 RS30 943129000820S 943129000820S RES.
0.1 OHM 5W CEMENT
CRF5EKR10X2
AMP1 RS40 943129000820S 943129000820S RES.
0.1 OHM 5W CEMENT
CRF5EKR10X2
AMP1 RS50 943129000820S 943129000820S RES.
0.1 OHM 5W CEMENT
CRF5EKR10X2
AMP1 VR20 943161000920S 943161000920S TRIM. RES.
EVMEGGA00B13
CVN3RE102B02
AMP1 VR30 943161000920S 943161000920S TRIM. RES.
EVMEGGA00B13
CVN3RE102B02
AMP1 VR40 943161000920S 943161000920S TRIM. RES.
EVMEGGA00B13
CVN3RE102B02
AMP1 VR50 943161000920S 943161000920S TRIM. RES.
EVMEGGA00B13
CVN3RE102B02
AMP2 PWB
(
CUP12071Y
)
AMP2 C101 ns
p
00MOA47505020 ELECT CAP.
4.7UF 50V
CCEA1HH4R7T
AMP2 C201 ns
p
90M-OA000150R ELECT CAP.
22UF 50V
CCEA1HROA220T
AMP2 C202 943133000590S 943133000590S FILM CAP.
330PF/100VDC POLYPROPYLENE
CCMP2A331JA02T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
74
