Marantz MR2020 - Page 39

10-2
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PA04-AM-STEREO
CIRCUIT BOARD [F Version]
PA04-CAPACITORS
CA02 F 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CA03 F 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CA04 F 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CA05 F 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CA11 F 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CA13 F 4822 124 23053 ELECT 1
µ
F 50V EJ10505010
CA14 F 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CA15 F 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CA16 F 4822 124 23056 ELECT 47
µ
F 16V EJ47601610
CA20 F 4822 124 23056 ELECT 47
µ
F 16V EJ47601610
CA21 F 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CA22 F 4822 124 40786 ELECT 2.2
µ
F 50V EJ22505010
CA23 F 4822 124 40786 ELECT 2.2
µ
F 50V EJ22505010
CA24 F 4822 124 23053 ELECT 1
µ
F 50V EJ10505010
PA04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR
±
10% 50V :
CA01 CA17-CA19
PLASTIC FILM CAPACITOR
±
5% 50V : CA06-CA10 CA12
PA04-RESISTOR
RA08 F FUSE 82
Ω
G 1/4W NF02820140
PA04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : RA01-RA07
PA04-SEMICONDUCTORS
DA01 F 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA02 F 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA03 F 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QA01 F IC MC13022P AM STEREO HC10078170
QA02 F IC 74HC4053 C-MOS HC705300B0
QA03 F 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QA04 F 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
PB04-MISCELLANEOUS
LA01 F I.F.T. COIL A7NRES-T1370Y
450kHz
LI71010120
XA01 F SERAMVIB. CSA3.6MGF103 FQ03604020
PH04-HEAD PHONE JACK
CIRCUIT BOARD
PH04-CAPACITORS
CH15 4822 126 12496 CER. 0.01
µ
F +80%-20% 50V DD38103010
CH16 4822 126 12496 CER. 0.01
µ
F +80%-20% 50V DD38103010
CH17 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
PB04-MISCELLANEOUS
JH01 4822 242 11018 JACK HEAD PHONE
HS10914-01-040
YJ01004500
LH10
JUMPER 75060501P0
LH14
PS04-SW ASSY
CIRCUIT BOARD
SS01 4822 276 14088 TACT SW. ALPS-SKQUAA SP01013280
SS02 4822 276 14088 TACT SW. ALPS-SKQUAA SP01013280
PS14-SW ASSY
CIRCUIT BOARD
SS11 4822 276 14088 TACT SW.ALPS-SKQUAA SP01013280
SS12 4822 276 14088 TACT SW.ALPS-SKQUAA SP01013280
PS54-IR ASSY C
IRCUIT BOARD
CS51 4822 126 10935 ELECT 100
µ
F 6.3V EJ10700610
QS51 4822 130 11494 PHOTO UNIT RPM6936-V4
IR SENSOR
HW10004210
SS51 4822 276 20508 PUSH SW. EVQ11L05R SP01013370
PS64-DOOR SW ASSY
CIRCUIT BOARD
SS61 4822 276 20508 PUSH SW. EVQ11L05R SP01013370
PU04-
µ
-COM ASSY
CIRCUIT BOARD
PU04-CAPACITORS
CF22 4822 126 11558 CER. 0.1
µ
F +80%-20% 50V DA17104110
CF49 /2 4822 126 10408 CER. 220pF ±10% B 50V DA16221110
CF50 /2 4822 126 10408 CER. 220pF ±10% B 50V DA16221110
CF51 /2 CER. 1500pF ±20% X 50V DA17152110
CF53 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CF54 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CF55 4822 126 10362 CER. 22pF ±5% SL 50V DA15220110
CF56 4822 126 10362 CER. 22pF ±5% SL 50V DA15220110
CF57 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CF58 4822 124 21894 ELECT 10
µ
F 16V EJ10601610
CF59 4822 124 23056 ELECT 47
µ
F 16V EJ47601610
CF60 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CF61 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CU01 4822 126 10513 CER. 47pF ±5% SL 50V DA15470110
CU02 4822 126 10513 CER. 47pF ±5% SL 50V DA15470110
CU03 4822 126 10513 CER. 47pF ±5% SL 50V DA15470110
CU04 4822 126 10364 CER. 100pF ±10% B 50V DA16101110
CU05 /2 4822 126 10513 CER. 47pF ±5% SL 50V DA15470110
CU08 /2 4822 122 31237 CER. 82pF ±5% CH 50V DD15820300
CU09 /2 4822 122 31205 CER. 47pF ±5% CH 50V DD15470300
CU10 /2 4822 126 12496 CER. 0.01
µ
F DC50V +80 -20% DD38103010
CU11 /2 4822 122 40617 CER. 0.1
µ
F DC50V +80 -20% DD38104010
CU12 /2 4822 126 11071 CER. 330pF ±10% B 50V DA16331110
CU13 /2 4822 124 40786 ELECT 2.2
µ
F 50V EJ22505010
CU14 /2 4822 126 10409 CER. 560pF ±10% B 50V DA16561110
CU17 4822 124 23295 BIG ELECT 0.022
µ
F 5V EX22300510
CU18 4822 126 10935 ELECT 100
µ
F 6.3V EJ10700610
CU19 4822 122 40586 CER. 0.01
µ
F ±20% 50V DA17103110
CU20 4822 126 10935 ELECT 100
µ
F 6.3V EJ10700610
CU21 4822 126 12867 ELECT. 1000
µ
F 6.3V OA108006Q0
CU24 4822 122 40589 CER. 0.047
µ
F ±10% F 50V DA17473110
CU27 4822 122 31823 CER. 15pF ±5% CH 50V DD15150300
CU28 4822 122 31823 CER. 15pF ±5% CH 50V DD15150300
CU29 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
CU30 4822 124 23053 ELECT 1
µ
F 50V EJ10505010
CU31 4822 124 23053 ELECT 1
µ
F 50V EJ10505010
CU32 4822 126 10408 CER. 220pF ±10% B 50V DA16221110
CU33 4822 122 33795 CER. 4700pF ±20% X 50V DA17472110
CU34 4822 126 10935 ELECT 100
µ
F 6.3V EJ10700610
CU35 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CU36 4822 124 22726 ELECT 4.7
µ
F 35V EJ47503510
CU37 4822 124 22726 ELECT 4.7
µ
F 35V EJ47503510
CU38 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CU39 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
CU41 4822 126 10364 CER. 100pF ±10% B 50V DA16101110
CU42 4822 126 10364 CER. 100pF ±10% B 50V DA16101110
