Marantz MR2020 - Page 40

10-3
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CU43 4822 126 10364 CER. 100pF ±10% B 50V DA16101110
CU44 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CU47 4822 122 40586 CER. 0.01
µ
F ±20% Y 50V DA17103110
CU48 /2 CER. 1500pF ±20% X 50V DA17152110
CU53 4822 126 12867 ELECT. 1000
µ
F 6.3V OA108006Q0
CU54 4822 122 40617 CER. 0.1
µ
F +80 -20% 50V DC DD38104010
CU55 /2 4822 126 12496 CER. 0.01
µ
F +80 -20% DC50V DD38103010
CU56 /2 4822 126 12496 CER. 0.01
µ
F +80 -20% DC50V DD38103010
CU57 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
CU58 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
CU59 4822 124 40786 ELECT 2.2
µ
F 50V EJ22505010
CU61
4822 126 10408 CER. 220P ±10% 50V DA16221110
CU64
CU65 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
PU04-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±
5% 50V : [CU45 CU46 : KK U]
PU04-RESISTORS
RU55 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
RU57 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
RU64 4822 117 10158 1
Ω
1/4W GG GG05010140
RU65 4822 117 10158 1
Ω
1/4W GG GG05010140
RU67 4822 052 10101 100
Ω
±5% 1/6W GG05101160
RU88 4822 050 23308 3.3M
Ω
±5% 1/6W GD05335160
PU04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : RF01-RF16
RF19-RF26 RF28-RF32
RF51-RF62 RT61-RT64
RU01-RU04
[RU05 RU07-RU12 : /02]
RU13-RU37 RU41-RU47 RU49
RU56 RU58-RU61
[RU62 : /02 U] [RU63 : /02 K KK]
RU69 RU71-RU74 RU76-RU87
RU89-RU93 RU98 RU99
PU04-SEMICONDUCTORS
DU01 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU02 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU03 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU04 JUMPER 75060501P0
DU05 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DU06 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DU07 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DU08 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DU09 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU10 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU12 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU13 4822 130 80837 DIODE HSS81TH 150V 150mA HD20027010
DU14 4822 130 80837 DIODE HSS81TD 150V 150mA HD20027010
DU15 4822 130 11585 L.E.D. SIM-22ST FOR DOOR HI20001210
DU16 JUMPER 75060501P0
QF51 4822 209 83631 IC NJM4558D-D HC10008090
QU01 4822 130 11586 PHOTO UNIT RPM-22PB
PHOTO-DOOR
HW10006210
QU02 4822 130 91368 PHOTO UNIT NJL5165KL
DISC SENSOR
HW10004090
QU03 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QU04 4822 130 61892 TRS. 2SD2144S U V HT421442A0
QU05 /2 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU06 /2 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QU07 /2 4822 209 17372 IC SAA6588 RDS DECODER HC10174490
QU08 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QU09 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QU10 4822 209 17376 MICROPROCESSOR
TMP87CS71F MR2020 E3E5
HU298JT000
QU14 4822 130 42682 DIG.TRS. DTA144ES UN4113
47K 47K
BA10002000
QU16 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU17 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QU18 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU19 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC
HT30001000
QU20 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QU21 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU22 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU23 4822 130 43313 TRS. 2SC3312 2SC1740SLN HT30002000
QU24 4822 130 43313 TRS. 2SC3312 2SC1740SLN HT30002000
QU25 4822 130 43313 TRS. 2SC3312 2SC1740SLN HT30002000
QU26 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC
HT10001000
QU29 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC
HT30001000
PU04-MISCELLANEOUS
LU01 /2 4822 242 73843 EMI FILTER 0.022
µ
F FM12223010
LU02 /2 4822 242 73843 EMI FILTER 0.022
µ
F FM12223010
SU01
4822 276 20508 PUSH SW. EVQ11L05R SP01013370
SU16
VU01 4822 135 00271 DISPLAY UNIT FL FTABA
11-BT-164GK
HQ30806410
XU01 4822 242 72236 CRYSTAL DT-38 32.768kHz XO001001T2
XU02 4822 242 72066 SERAMVIB. CST8.0MHz MT FQ08004010
XU03 /2 4822 242 10857 CRYSTAL 4.332MHz AT-49 JX04003260
PX04-SOUND CONT. H.P AMP
CIRCUIT BOARD
PX04-CAPACITORS
CE09 4822 124 22703 ELECT. 0.22
µ
F ±20% 50V OA22405020
CE10 4822 124 22703 ELECT. 0.22
µ
F ±20% 50V OA22405020
CE11 4822 124 22273 ELECT. 0.47
µ
F ±20% 50V OA47405020
CE12 4822 124 22273 ELECT. 0.47
µ
F ±20% 50V OA47405020
CE17 4822 122 40617 CER. 0.1
µ
F +80 -20% 50V DC DD38104010
CE18 4822 124 41539 ELECT. 47
µ
F ±20% 16V RA-2 OA47601620
CE19 4822 124 41539 ELECT. 47
µ
F ±20% 16V RA-2 OA47601620
CE20 4822 124 90354 ELECT. 100
µ
F 16V OA10701620
CE21 4822 124 90354 ELECT. 100
µ
F 16V OA10701620
CE27 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE28 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE31 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE32 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE35 4822 124 41543 ELECT. 1
µ
F ±20% 50V RA-2 OA10505020
CE36 4822 124 41543 ELECT. 1
µ
F ±20% 50V RA-2 OA10505020
CE37 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE38 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE41 4822 121 42327 FILM 470pF ±5% 50V DF15471350
CE42 4822 121 42327 FILM 470pF ±5% 50V DF15471350
