Marantz MR2020 - Page 41

POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CE45 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CE46 4822 122 40617 CER. 0.1
µ
F +80%-20% 50V DD38104010
CH07 5322 122 32143 CER. 22pF ±5% 50V DD15220300
CH08 5322 122 32143 CER. 22pF ±5% 50V DD15220300
CH09 4822 124 41539 ELECT. 47
µ
F ±20% 16V RA-2 OA47601620
CH10 4822 124 41539 ELECT. 47
µ
F ±20% 16V RA-2 OA47601620
CH11 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CH12 4822 124 41539 ELECT. 47
µ
F ±20% 16V RA-2 OA47601620
CH18 4822 124 41539 ELECT. 47
µ
F 16V OA47601620
CX01 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX02 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX05 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX08 4822 124 41539 ELECT. 47
µ
F 16V RA-2 OA47601620
CX09 4822 124 90352 ELECT. 10
µ
F 16V OA10601620
CX10 4822 124 90352 ELECT. 10
µ
F 16V OA10601620
CX11 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX12 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX13 4822 124 90352 ELECT. 10
µ
F 16V OA10601620
CX14 4822 124 90352 ELECT. 10
µ
F 16V OA10601620
CX17 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX18 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX19 4822 124 22273 ELECT. 0.47
µ
F ±20% 50V OA47405020
CX20 4822 124 22273 ELECT. 0.47
µ
F ±20% 50V OA47405020
CX21 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX22 4822 124 90357 ELECT. 2.2
µ
F 50V OA22505020
CX23 5322 122 32143 CER. 22pF ±5% CH 50V BLK DD15220300
CX24 5322 122 32143 CER. 22pF ±5% CH 50V BLK DD15220300
CX25 4822 124 90357 ELECT. 2.2
µ
F ±20% 50V RA-2 OA22505020
CX26 4822 124 90357 ELECT. 2.2
µ
F ±20% 50V RA-2 OA22505020
CX27 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX28 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX29 4822 124 90352 ELECT. 10
µ
F 16V OA10601620
CX70 4822 124 11574 ELECT 1000
µ
F 16V RE3 EA10801670
CX71 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
CX72 4822 124 41539 ELECT. 47
µ
F 16V OA47601620
CX73 4822 122 30043 CER. 0.01
µ
F +80%-20% 50V DK18103310
PX04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR
±
10% 50V :
CE33 CE34 CE39 CE40 CH05
CH06 CH13 CH14 CX03 CX16
CX81 CX82
PLASTIC FILM CAPACITOR
±
5% 50V : CE01-CE08 CE15
CD16 CE25 CE26 CE29 CE30
CE43 CE44 CE47 CH01-CH04
CX15 CX31 CX32
PX04-RESISTOR
RX72 4822 111 90967 FUSE 4.7
Ω
1/4W NF05047140
PX04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : RE01-RE38
RH03-RH16 RN01-RN04
RX01-RX08 RX11-RX26
RX31-RX48 RX70 RX71
PX04-SEMICONDUCTORS
QE01 4822 209 17382 IC TEA6321 DSC HC10170490
QE02 4822 130 61892 TRS. 2SD2144S U V HT421442A0
QE03 4822 209 83631 IC NJM4558D-D HC10008090
QE04 4822 209 83631 IC NJM4558D-D HC10008090
QH01 4822 209 82362 IC NJM4556D HC10016090
QN01
4822 130 43818 TRS. 2SC2878 A BRANK HT328782A0
QN04
QX01 4822 209 83631 IC NJM4558D-D HC10008090
QX02 4822 209 83631 IC NJM4558D-D HC10008090
QX03 4822 209 83631 IC NJM4558D-D HC10008090
QX04 4822 209 17381 IC PQ05RF2 REQ.5V 2A HC31905320
QX05
4822 130 43818 TRS. 2SC2878 A BRANK HT328782A0
QX08
QX09 4822 209 83631 IC NJM4558DD HC10008090
QX70 4822 130 61892 TRS. 2SD2144S U V HT421442A0
PX04-MISCELLANEOUS
LH01 4822 157 62898 CHOKE COIL 180
µ
H J LC11843800
LH03 4822 157 62898 CHOKE COIL 180
µ
H J LC11843800
LH05 4822 157 62898 CHOKE COIL 180
µ
H J LC11843800
LH15 JUMPER 75060501P0
LH16 JUMPER 75060501P0
LX01 4822 157 60122 CHOKE COIL 4.7
µ
H J LC14723800
PX54-AUX-IN MONI-OUT
REMOTE CIRCUIT BOARD
PX54-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR
±
10% 50V :
CX51-CX55
PX54-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±
5% 1/6W : RX51-RX54
PX54-MISCELLANEOUS
JX51 4822 265 11573 TERMINAL MONI-OUT AUX-IN YT02041230
JX52 4822 265 10684 TERMINAL SUB WOOFER
RCA-1PIN
YT02011020
LX51
4822 157 62908 CHOKE COIL 2.2
µ
H J LC12223800
LX55
10-4
