NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
17
POS.
NO
VERS.
COLOR
PA RT NO.
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
POS.
NO
VERS.
COLOR
PA R T NO .
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
P101-C-AMP CIRCUIT BOARD
P101-CAPAITORS
C101
4822 124 80771 ELECT 100 F 100V RA-2 OA10710020
C108
C109 FILM 0.068
F 5% 100V OF55683540
C110 FILM 0.068
F 5% 100V OF55683540
C111
FILM 0.047 F 5% 100V OF55473540
C114
C161
4822 124 80771 ELECT 100 F 100V RA-2 OA10710020
C164
C165
FILM 0.01 F 5% 100V OF55103540
C168
C801
4822 124 12275 ELECT 470 F M 100V RA-2 OA47710020
C828
C829 FILM 0.022
F 5% 100V OF55223540
C830 FILM 0.022
F 5% 100V OF55223540
C851 CER. 0.1
F +80 -20% 50V DD38104040
C852 4822 124 22695 ELECT 2200 F M 35V RA-2 OA22803520
C853 4822 124 42182 ELECT 3.3
F M 50V RA-2 OA33505020
CN01 4822 124 90365 ELECT 220
F M 25V RA-2 OA22702520
CN02 4822 124 90365 ELECT 220
F M 25V RA-2 OA22702520
CN03 4822 124 22274 ELECT 4.7
F M 50V RA-2 OA47505020
CN04 4822 124 22276 ELECT 47
F M 50V RA-2 OA47605020
CN05 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CN06 CER. 0.1
F +80 -20% 50V DD38104040
CN32 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
P101-CAPACITORS(COMMON)
C
PLASTIC FILM CAPACITOR
5% 50V : CN31
P101-RESISTORS
R101
100 1% 1/4W GM11410000
R104
R105
5.6k 5% 3W GA05562030
R108
R109
10 1% 1/4W GM114100G0
R112
R113 68.1
1% 1/4W GM114681G0
R114 68.1
1% 1/4W GM114681G0
R115 TRIMMING RH068 CERMET
330B 0.3W
RA03311100
R116 TRIMMING RH068 CERMET
330B 0.3W
RA03311100
R117 TRIMMING RH068 CERMET
100B 0.3W
RA01011100
R118 TRIMMING RH068 CERMET
100B 0.3W
RA01011100
R119 5322 116 51677 39
5% 2W GA05390020
R120 5322 116 51677 39
5% 2W GA05390020
R121
4822 117 10158 1 5% 1/4W GG05010140
R136
R137
4822 116 80153 0.18 10% 5W GO10182050
R152
R153 4822 053 11109 10
5% 2W GA05100020
R154 4822 053 11109 10
5% 2W GA05100020
R161
1k 1% 1/4W GM11410010
R164
R165
27.4k 1% 1/4W GM11427420
R168
R169
33.2 1% 1/4W GM114332G0
R172
R173 162
1% 1/4W GM11416200
R174 162
1% 1/4W GM11416200
R851 4822 117 10158 1 5% 1/4W GG05010140
RN39 4822 050 21502 1.5k 5% 1/4W GG05152140
RN40 4822 050 21502 1.5k 5% 1/4W GG05152140
RN51 4822 050 21502 1.5k 5% 1/4W GG05152140
RN52 4822 050 21502 1.5k 5% 1/4W GG05152140
P101-RESISTORS COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : R852 R853
RN07-RN17 RN19-RN29
RN31-RN38 RN41-RN44
RN47-RN50 RN53-RN62
P101-SEMICONDUCTORS
D801
DIODE FSF10A20 HD20056100
D808
D851
4822 130 82421 DIODE 1D3 1A/200V HD20002710
D856
DN01 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
DN02 4822 130 80837 DIODE HSS81TD 150V 150MA HD20027010
DN03
4822 130 82421 DIODE 1D3 1A/200V HD20002710
DN06
Q101 TRS. 2SC5171 HT35171000
Q102 TRS. 2SC5171 HT35171000
Q103 TRS. 2SA1930 HT11930000
Q104 TRS. 2SA1930 HT11930000
Q105
TRS. 2SC2837 Y HT328371C0
Q112
Q113
TRS. 2SA1186 Y HT111861C0
Q120
Q131
Q134
TRS. 2SC3987 50V 3A
HFE4000
HT33987000
Q161 TRS. 2SC2911 S HT329111B0
Q162 TRS. 2SC2911 S HT329111B0
Q163 TRS. 2SA1209 S HT112091B0
Q164 TRS. 2SA1209 S HT112091B0
QN01 4822 209 83312 IC TA7317P HC10042050
QN02 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QN03 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN04 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN05 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QN06 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN07 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN08 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN09 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QN10 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QN11 4822 130 43283 TRS. 2SC2705 O O
R
Y HT327052A0
