NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
18
POS.
NO
VERS.
COLOR
PA RT NO.
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
POS.
NO
VERS.
COLOR
PA R T NO .
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
P101-MISCELLANEOUS
LN01 4822 280 10343 RELAY VS-24MBU-551-UC
GOLD CONTACT
LY10240270
LN02 4822 280 10343 RELAY VS-24MBU-551-UC
GOLD CONTACT
LY10240270
P701-V-AMP CIRCUIT BOARD
P701-CAPACITORS
C701
ELECT 47 F M 100V RA-2 OA47610020
C708
C709
4822 123 30086 MICA 47pF J 500V DF35470520
C712
C713
FILM 4700pF 5% 100V OF55472540
C716
C717
FILM 0.01 F 5% 100V OF55103540
C720
C721
4822 124 80771 ELECT 100 F 100V RA-2 OA10710020
C724
C871
4822 124 12275 ELECT 470 F M 100V RA-2 OA47710020
C878
C879 FILM 0.022
F 5% 100V OF55223540
C880 FILM 0.022
F 5% 100V OF55223540
P701-RESISTORS
R701
46.4 1% 1/4W GM114464G0
R704
R705
9965 000 00596 22.6k 1% 1/4W GM11422620
R708
R709
1k 1% 1/4W GM11410010
R724
R725
4822 053 10682 6.8k 5% 1W GA05682010
R728
R729
442 1% 1/4W GM11444200
R732
R733
33.2 1% 1/4W GM114332G0
R736
R737
56.2 1% 1/4W GM114562G0
R740
R741 4.64k
1% 1/4W GM11446410
R742 4.64k
1% 1/4W GM11446410
R743
10 1% 1/4W GM114100G0
R746
R747
1k 1% 1/4W GM11410010
R750
R751
33.2 1% 1/4W GM114332G0
R754
R755 162
1% 1/4W GM11416200
R756 162
1% 1/4W GM11416200
R757
33.2 1% 1/4W GM114332G0
R760
R761 82.5
1% 1/4W GM114825G0
R762 82.5
1% 1/4W GM114825G0
R763
68.1 1% 1/4W GM114681G0
R766
R767
1k 1% 1/4W GM11410010
R770
R791 VAR. 10KA*2 MASTER VL L RM01031190
R792 VAR. 10KA*2 MASTER VL R RM01031190
R793
R796
TRIMMING RH068 CERMET
220B 0.3W
RA02211100
R871 4822 050 21108 1 5% 1/2W GG05010120
R872 4822 050 21108 1 5% 1/2W GG05010120
P701-SEMICONDUCTORS
D871
DIODE 11DF2 1A 200V FRD HD20057100
D878
D701
D704
L.E.D. GL3HS8
(SUNSET ORANGE)
HI10111320
D705 4822 130 82421 DIODE 1D3 1A/200V HD20002710
Q701
4822 130 43813 TRS. 2SC2362K G RANK HT323621G0
Q704
Q705
TRS. 2SA1016K G RANK HT110161G0
Q708
Q709
F.E.T. 2SK117 BL RANK HF201171D0
Q712
Q713 TRS. 2SA1016K G HT110161G0
Q714 TRS. 2SA1016K G HT110161G0
Q715 4822 130 43813 TRS. 2SC2362K G HT323621G0
Q716 4822 130 43813 TRS. 2SC2362K G HT323621G0
Q717 TRS. 2SA1209 S HT112091B0
Q718 TRS. 2SA1209 S HT112091B0
Q719 TRS. 2SC2911 S HT329111B0
Q720 TRS. 2SC2911 S HT329111B0
Q721 4822 130 43192 TRS. 2SC1775A E HT317751E0
Q722 4822 130 43192 TRS. 2SC1775A E HT317751E0
Q723 4822 130 43617 TRS. 2SA872A E HT108721E0
Q724 4822 130 43617 TRS. 2SA872A E HT108721E0
Q725 TRS. 2SC2911 S HT329111B0
Q726 TRS. 2SC2911 S HT329111B0
Q727 TRS. 2SA1209 S HT112091B0
Q728 TRS. 2SA1209 S HT112091B0
Q729 TRS. 2SC5171 HT35171000
Q730 TRS. 2SC5171 HT35171000
Q731 TRS. 2SA1930 HT11930000
Q732 TRS. 2SA1930 HT11930000
P701-MISCELLANEOUS
L701 9965 000 01570 RELAY ED2-24V LY20240470
L702 9965 000 01570 RELAY ED2-24V LY20240470
PF01-POWER CONNECT
CIRCUIT BOARD
CF01 CER. CAP.DE1607-1F 103M-KH DK17103910
PL01-POWER LED
CIRCUIT BOARD
DL81 L.E.D. BLU LED FOR POWER HI10039080
DL82 4822 130 80326 L.E.D. RED LED FO
R C
LIP HI10062320
