NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
19
POS.
NO
VERS.
COLOR
PA RT NO.
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
POS.
NO
VERS.
COLOR
PA R T NO .
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
PL02-TEMP LED
CIRCUIT BOARD
DL91 4822 130 80326 L.E.D. RED LED FOR TEMP HI10062320
DL92
4822 130 11363 L.E.D. GRN LED FOR TEMP HI10095320
DL95
PM01-FAN CONTROL
CIRCUIT BOARD
PM01-CAPACITORS
C891 4822 124 81133 ELECT 4700
F 25V RA-2 OA47802520
C892 CER. 0.1
F +80 -20% 50V DD38104040
C893 4822 124 90357 ELECT 2.2
F M 50V RA-2 OA22505020
CL01 4822 124 22274 ELECT 4.7
F M 50V RA-2 OA47505020
CL02 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL03 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CL04 CER. 0.1
F +80 -20% 50V DD38104040
CM01 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CM02 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CM03 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
CM04 4822 124 90362 ELECT 22
F M 50V RA-2 OA22605020
CM06 CER. 0.1
F +80 -20% 50V DD38104040
CM07 4822 124 22571 ELECT 10
F M 50V RA-2 OA10605020
PM01-RESISTORS
R891 4822 117 10158 1 5% 1/4W GG05010140
RM01 4822 053 10151 150
5% 1W GA05151010
RM03 4822 050 21022 1k
5% 1/2W GG05102120
P1M1-RESISTORS COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : R892 RL01-RL21
RL32 RN33 RL34 RM02
RM04-RM16 RM21 RM22
PM01-SEMICONDUCTORS
D891
DIODE 11DF2 1A 200V FRD HD20057100
D894
D895 4822 130 82421 DIODE 1D3 1A/200V HD20002710
DM01 4822 130 82421 DIODE 1D3 1A/200V HD20002710
DL01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DL03
DL06
4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QL01 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QL02 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL03 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL04 4822 130 63211 DIG. TRS. DTA114TS/UN4115
10K
BA10004000
QL05 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QL06 4822 130 63211 DIG. TRS. DTA114TS/UN4115
10K
BA10004000
QL07
QL11
4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QL12 4822 130 63211 DIG. TRS. DTA114TS/UN4115
10K
BA10004000
QL13 4822 130 63211 DIG. TRS. DTA114TS/UN4115
10K
BA10004000
QL16 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QL17 4822 130 61227 DIG. TRS. DTA114ES/UN4111
10K 10K
BA10001000
QL18 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QM01 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QM02 TRS. 2SC3987 50V 3A
HFE4000
HT33987000
QM03 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QM04 4822 130 61189 DIG. TRS. DTC114TS/UN4215
10K
BA20004000
QM05 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QM06 4822 130 60588 DIG. TRS. DTC114ES/UN4211
10K 10K
BA20001000
QM07 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QM09 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
QM10 4822 130 63211 DIG. TRS. DTA114TS/UN4115
10K
BA10004000
QM11 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267 ETC.
HT10001000
PM02-TEMP SENSOR
CIRCUIT BOARD
QM91 VARISTOR
PTH487A01BF222TS 2.2KW
HP00042230
QM92 4822 126 90009 VARISTOR
PTH487A01BD222TS 2.2KW
HP00029230
QM94 VARISTOR PTH487A01
BH222TS POSISTER
HP00023230
PM03-TEMP. SENSOR SUB
CIRCUIT BOARD
QM93 4822 130 42848 VARISTOR POSISTOR PTH487
(01BB-120)
HP00009230
PV01-INPUT CIRCUIT BOARD
PV01-CAPACITORS
CV01 CER. 0.1
F +80 -20% 50V DD38104040
CV02 CER. 0.1
F +80 -20% 50V DD38104040
PV01-SEMICONDUCTORS
DV01 4822 130 82421 DIODE 1D3 1A/200V HD20002710
DV02 4822 130 82421 DIODE 1D3 1A/200V HD20002710
DV03 4822 130 82421 DIODE 1D3 1A/200V HD20002710
PV01-MISCELLANEOUS
JV01 9965 000 02540 JACK NC3FAH2 4P YJ01004340
JV02 9965 000 02540 JACK NC3FAH2 4P YJ01004340
JV03 4822 290 81598 TERMINAL 2P RCA JACK
YKC21-3255 (GOLD)
YT02021130
LV01 9965 000 01576 RELAY MR82-24USR LY20240480
LV02 9965 000 01576 RELAY MR82-24USR LY20240480
LV03 9965 000 01576 RELAY MR82-24USR LY20240480
SV01 SLIDE SW. SSSF113-S06N1 SS01030300
