Specifications
0
RMS Power output (Simultaneous drive of both channels) : 200 W x 2 (8 Ω/ohms load, 1 kHz, T.H.D. 0.05 %)
400 W x 2 (4 Ω/ohms load, 1 kHz, T.H.D. 0.1 %)
0
Total harmonic distortion
(1 kHz, simultaneous drive of both channels, 100 W, 8 Ω/ohms load) :
0.005 %
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 50 kHz ±3 dB
0
Damping factor (8 Ω/ohms load, 20 Hz – 20 kHz) : 500
0
Input sensitivity/Input impedance
PHONO (MC Low) :
280 μV/33 Ω/ohms
PHONO (MC High) :
280 μV/133 Ω/ohms
PHONO (MM) :
2.6 mV/47 kΩ/kohms
BALANCED :
880 mV/40 kΩ/kohms
CD/LINE/RECORDER :
440 mV/20 kΩ/kohms
POWER AMP :
1.5 V/20 kΩ/kohms
0
Maximum allowable PHONO input level (1 kHz)
MC :
8 mV
MM :
80 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MC) :
76 dB (0.5 mV Input, 1 W Output)
PHONO (MM) :
88 dB (5 mV Input, 1 W Output)
BALANCED :
111 dB (4 V Input, Rated output)
CD/LINE/RECORDER :
111 dB (2 V Input, Rated output)
0
Power requirement : AC 230 V, 50/60 Hz
0
Power consumption : 270 W
0
Power consumption in standby mode : 0.3 W
For the purpose of improvement, the specifications and design are subject to change without notice.
