Marantz PM6002 - Page 13

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
1
/
N1B 90M285W270010 90M285W270010 BUTTON KNOB POWER BLACK CBC1A122K92
1
/
N1S 90M44BW270210 90M44BW270210 BUTTON KNOB POWER SILVER CBC1A122R6G13
2
/
N1B 90M44BW270060 90M44BW270060 BUTTON KNOB SPEAKER CBC1A123K92
2
/
N1S 90M44BW270260 90M44BW270260 BUTTON KNOB SPEAKER SILVER CBC1A123R6G13
3
/
N1B 00M274W154030 00M274W154030 KNOB KNOB FOR BALANCE
(
KBN1A115
)
CBN1A115K92
3
/
N1S 00M274W154230 00M274W154230 KNOB BALANCE KNOB SILVER CBN1A115R6G13
4
/
N1B 00M44BW158110 00M44BW158110 WINDOW INDICATOR BLACK/GOLD CGU1A377Z
4
/
N1S 00M44BW158210 00M44BW158210 WINDOW INDICATOR SILVER CGU1A377Y
5
/
N1B 00M44BW154010 00M44BW154010 KNOB VOLUME KNOB BLACK CGX1A371ZA
5
/
N1S 00M44BW154210 00M44BW154210 KNOB VOLUME KNOB SILVER CGX1A371XA
6
/
N1B 00M44BW154020 00M44BW154020 KNOB FUNCTION KNOB BLACK CGX2A371ZA
6
/
N1S 00M44BW154220 00M44BW154220 KNOB FUNCTION KNOB SILVER CGX2A371XA
7
/
N1B 00M24AW251010 00M24AW251010 BADGE NEW MZ BADGE CGB1A117
7
/
N1S 00M24AW251020 00M24AW251020 BADGE NEW MZ BADGE SILVER CGB1A117G
8
/
N1B 00M44CW248010 00M44CW248010 PANEL PANEL FRONT BLACK CKM1A165 CKM1A165YC23
8
/
N1S 00M44CW248210 00M44CW248210 PANEL PANEL FRONT SILVER CKM1A165 CKM1A165YC40
9
/
N1B 00M44BW105010 00M44BW105010 CHASSIS PANEL SUB BLACK CGW1A409R4K92
9
/
N1S 00M44BW105210 00M44BW105210 CHASSIS PANEL SUB SILVER CGW1A409R6G13
10 00M274W355020 00M274W355020 LENS INDICATOR STANDBY CGL1A174
11 00M44BW355020 00M44BW355020 LENS INDICATOR MUTE CGL1A239
12 00M44BW355010 00M44BW355010 LENS INDICATOR FUNCTION CGL1A238
14 ns
p
ns
p
CHASSIS BOTTOM CHASSIS PM6002 CUA3A182
15 ns
p
ns
p
BRACKET A4-97-2814 CMD1A366
16 ns
p
ns
p
HEATSINK HEATSINK CMY1A286
17 ns
p
ns
p
BRACKET A4-97-2815 CMD1A367
18 ns
p
ns
p
PANEL REAR PANEL PM6002 CKF4A187H
19 ns
p
ns
p
WASHER WASHER GROUND COPPER CNW1A035
20 00M32CW107010 00M32CW107010 SHEET CUSHION FOOT CHG1A360
21
/
N1B 00M243W057010 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
21
/
N1S 00M243W057210 00M243W057210 LEG LEG FOR SILVER CKL2A042H46
22 ns
p
ns
p
HOLDER HOLDER PWB CHE170
23 ns
p
ns
p
SUPPORT SJBS-26R KRE1A006
24 ns
p
ns
p
BUFFER RUBBER CHG1A113
25 ns
p
ns
p
TERMINAL GROUND TERMINAL KMA1A006
26 ns
p
ns
p
BUFFER CUSHION STOPPER CHG1A162
BN91 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN91
P1
/
N1B ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11954D
P1
/
N1S ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11954E
P2 ns
p
ns
p
PWB ASSY MAIN PWB ASSY COP11833F
PWR1 90M-TS003190R 90M-TS003190R TRANSF. # TROIDAL PM6002 CLT5Z018ZE
RT01 00MYJ04002640 00MYJ04002640 INLET ! R-301
(
21
)
AC INLET CJJ8A006ZW
RT91 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN91A
90M-FC500030R 90M-FC500030R FERRITE CORE FERRITE RING 29X7.7X19 CLZ9W003Z
90M-FC500030R 90M-FC500030R FERRITE CORE FERRITE RING 29X7.7X19 CLZ9W003Z
PACKING
00M44CW851310 00M44CW851310 USER GUIDE USER GUIDE PM6002 N CQX1A1261Z
00MZK26CW0010 00MZK26CW0010 UNIT KIT REMOTE CONTROLLER RC002PM CARTPM4001RC
W001 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250V CJA2B054Z
NOT STANDARD SPARE PART
ns
p
00M44CW801010 PACKING CASE PACKING CASE PM6002 CPG1A844Z
ns
p
00M44CW809010 CUSHION CUSHION CPS2A797
13
/
N1B ns
p
00M274W257030 LID TOP LID BLACK KBC1A104 CKC3A104K117
13
/
N1S ns
p
00M274W257130 LID TOP LID SILVER KBC1A104 CKC3A104G14
POS. NO.
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
19
