Marantz PM6002 - Page 18

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT C920 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C921 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
INPUT C922 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
INPUT C923 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C926 ns
p
00MOA22605020 ELECT CAP. 22UF 25V CCEA1EH220T
INPUT C927 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C928 ns
p
ns
p
CER. CAP. 0.043UF 50V Z CCFT1H473ZF
INPUT C929 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
INPUT CN12 ns
p
ns
p
CONN. STRAIGHT 4PIN CJP04GA01ZY
INPUT CN33 ns
p
ns
p
CONN. 00906-0027 4P STRAIGHT CJP04GA19ZY
INPUT CN35 ns
p
ns
p
CONN. 00906-0027 4P STRAIGHT CJP04GA19ZY
INPUT CN37 ns
p
ns
p
CONN. STRAIGHT 2PIN CJP02GA01ZY
INPUT CN38 ns
p
ns
p
CONN. STRAIGHT 2PIN CJP02GA01ZY
INPUT CN55 ns
p
ns
p
CONN. STRAIGHT 2PIN CJP02GA01ZY
INPUT CN90 ns
p
ns
p
CONN. 3P WAFER CJP03GA90ZY
INPUT CN92 ns
p
ns
p
CONN. STRAIGHT 4PIN CJP04GA01ZY
INPUT CN95 ns
p
ns
p
CONN. 10P STRAIGHT CJP10GA19ZY
INPUT D251 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D252 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D301 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D302 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D303 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D304 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D305 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D306 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D307 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D308 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D373 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D374 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D383 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D388 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D391 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D392 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D901 90M-HE200330R 90M-HE200330R DIODE ! BU804F HVDKBU804F
INPUT D911 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V CVD11EQS10GT
INPUT D912 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V CVD11EQS10GT
INPUT D913 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V CVD11EQS10GT
INPUT D914 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V CVD11EQS10GT
INPUT D915 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D921 90M-HD302480R 90M-HD302480R ZENER DIODE ZJ15B 1/2W CVDZJ15BT
INPUT D922 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D923 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D924 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
INPUT D925 90M-HD302490R 90M-HD302490R ZENER DIODE ZJ6.2B 1/2W CVDZJ6.2BT
INPUT ET01 ns
p
ns
p
TERMINAL EARTH PLATE CNE75
INPUT GND1 ns
p
ns
p
TERMINAL MET37-0002 HJT1A025
INPUT IC11 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC21 00MHC10309030 00MHC10309030 IC LC78212 HVILC78212
INPUT IC22 00MHC10309030 00MHC10309030 IC LC78212 HVILC78212
INPUT IC23 90M-HC109460R 90M-HC109460R IC NJM2114M HVINJM2114M
INPUT IC93 90M-HC300480R 90M-HC300480R IC ! KA7815-ABTU HVIMC7815C
INPUT IC94 90M-HC300490R 90M-HC300490R IC ! KA7915-ABTU HVIMC7915C
INPUT IC95 90M-HC300500R 90M-HC300500R IC ! KA7805-ABTU HVIMC7805C
INPUT J101 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J102 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J103 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J104 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J105 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J106 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J107 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J108 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J110 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J111 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J112 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J113 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J114 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
INPUT J115 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
