Marantz PM6002 - Page 21

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT JK11 90M-YT003110R 90M-YT003110R TERMINAL CINCH 2P
(
GOLD
)
AUDIO CJJ4N060Z
INPUT JK12 90M-YT004520R 90M-YT004520R TERMINAL CINCH 4P AUDIO GOLD CJJ4P058Z
INPUT JK13 90M-YT004520R 90M-YT004520R TERMINAL CINCH 4P AUDIO GOLD CJJ4P058Z
INPUT JK14 90M-YT004520R 90M-YT004520R TERMINAL CINCH 4P AUDIO GOLD CJJ4P058Z
INPUT JK15 90M-YT003110R 90M-YT003110R TERMINAL CINCH 2P
(
GOLD
)
AUDIO CJJ4N060Z
INPUT JK31 90M-YT005410R 90M-YT005410R TERMINAL SPEAKER 8P CJJ5Q015Z
INPUT JW11 ns
p
ns
p
CORD WIRE ASSY CWEH202080PP
INPUT L101 ns
p
ns
p
COIL COIL TOROIDAL CLU9S004Z
INPUT L102 ns
p
ns
p
COIL COIL TOROIDAL CLU9S004Z
INPUT L363 90M-LC107310R 90M-LC107310R COIL 0.5UH K CLEY0R5KAK
INPUT L364 90M-LC107310R 90M-LC107310R COIL 0.5UH K CLEY0R5KAK
INPUT Q281 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q282 00MHT805501B0 00MHT805501B0 TRS. KTC2874B HVTKTC2874BT
INPUT Q301 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q302 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q303 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q304 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q305 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q306 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q307 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q308 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
INPUT Q309 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
INPUT Q310 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
INPUT Q311 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
INPUT Q312 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
INPUT Q325 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
INPUT Q326 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
INPUT Q335 00MHT800941B0 00MHT800941B0 TRS. KTC3206Y HVTKTC3206YAT
INPUT Q336 00MHT800941B0 00MHT800941B0 TRS. KTC3206Y HVTKTC3206YAT
INPUT Q345 00MHT334191Y0 00MHT334191Y0 TRS. 2SC3419Y HVT2SC3419Y
INPUT Q346 00MHT334191Y0 00MHT334191Y0 TRS. 2SC3419Y HVT2SC3419Y
INPUT Q347 00MHT800941B0 00MHT800941B0 TRS. KTC3206Y HVTKTC3206YAT
INPUT Q348 00MHT800941B0 00MHT800941B0 TRS. KTC3206Y HVTKTC3206YAT
INPUT Q349 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
INPUT Q350 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
INPUT Q351 90M-HT300940R 90M-HT300940R TRS. 2SC4883A HVT2SC4883A
INPUT Q352 90M-HT300940R 90M-HT300940R TRS. 2SC4883A HVT2SC4883A
INPUT Q353 90M-HT100690R 90M-HT100690R TRS. 2SA1859A HVT2SA1859A
INPUT Q354 90M-HT100690R 90M-HT100690R TRS. 2SA1859A HVT2SA1859A
INPUT Q355 00MHT344683A0 00MHT344683A0 TRS. ! 2SC4468P HVT2SC4468
INPUT Q356 00MHT344683A0 00MHT344683A0 TRS. ! 2SC4468P HVT2SC4468
INPUT Q357 00MHT116953A0 00MHT116953A0 TRS. ! 2SA1695P HVT2SA1695
INPUT Q358 00MHT116953A0 00MHT116953A0 TRS. ! 2SA1695P HVT2SA1695
INPUT Q371 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q372 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q379 90M-HT100390R 90M-HT100390R TRS. KSA1175Y HVTKSA1175YT
INPUT Q385 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q386 90M-HT100390R 90M-HT100390R TRS. KSA1175Y HVTKSA1175YT
INPUT Q391 90M-HT100390R 90M-HT100390R TRS. KSA1175Y HVTKSA1175YT
INPUT Q392 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q393 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q394 00MHT327851H0 00MHT327851H0 TRS. KSC2785Y HVTKSC2785YT
INPUT Q921 90M-HT800040R 90M-HT800040R TRS. ! KSC2316Y HVTKSC2316YT
INPUT Q922 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
INPUT Q923 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
INPUT Q924 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
INPUT R101 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
INPUT R102 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
INPUT R103 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R104 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R105 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R106 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R109 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R110 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R111 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R112 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R113 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
27
