Marantz PM6002 - Page 23

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT R286 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R287 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R288 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681T
INPUT R289 ns
p
ns
p
RES. 680 OHM 1/5W J CRD20TJ681T
INPUT R290 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
INPUT R291 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
INPUT R292 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
INPUT R293 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
INPUT R294 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
INPUT R295 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
INPUT R296 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
INPUT R297 ns
p
ns
p
RES. 1.2K OHM 1/5W J CRD20TJ122T
INPUT R298 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
INPUT R299 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
INPUT R300 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
INPUT R301 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
INPUT R302 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
INPUT R303 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
INPUT R304 ns
p
ns
p
RES. 300 OHM 1/5W J CRD20TJ301T
INPUT R305 ns
p
ns
p
RES. 300 OHM 1/5W J CRD20TJ301T
INPUT R306 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R307 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104T
INPUT R308 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R309 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R310 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
INPUT R311 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
INPUT R312 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R313 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R314 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R315 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R316 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R317 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R318 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R319 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R320 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R321 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
INPUT R322 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
INPUT R323 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
INPUT R324 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
INPUT R325 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105T
INPUT R327 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R328 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R331 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R332 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R333 ns
p
ns
p
RES. 820 OHM 1/5W J CRD20TJ821T
INPUT R334 ns
p
ns
p
RES. 820 OHM 1/5W J CRD20TJ821T
INPUT R335 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R336 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R337 ns
p
ns
p
RES. 10 OHM 1/4W KRD25FJ100T
INPUT R338 ns
p
ns
p
RES. 10 OHM 1/4W KRD25FJ100T
INPUT R339 ns
p
ns
p
RES. 10 OHM 1/4W KRD25FJ100T
INPUT R340 ns
p
ns
p
RES. 10 OHM 1/4W KRD25FJ100T
INPUT R341 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
INPUT R342 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
INPUT R343 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
INPUT R344 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
INPUT R345 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R346 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R347 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R348 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
INPUT R349 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
INPUT R350 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
INPUT R351 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
INPUT R352 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
INPUT R353 ns
p
ns
p
RES. 220 OHM 1/4W J CRD25TJ221T
INPUT R354 ns
p
ns
p
RES. 220 OHM 1/4W J CRD25TJ221T
INPUT R355 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
29
