Marantz PM6002 - Page 25

P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT VR33 90M-RA001140R 90M-RA001140R TRIM. RES. RH0638C-102 HVN1RA102B01T
INPUT VR34 90M-RA001140R 90M-RA001140R TRIM. RES. RH0638C-102 HVN1RA102B01T
MASTER VOLUME PWB
(
CUP11954-2
)
M-VOL. BN12 ns
p
ns
p
CORD WIRE ASSY 2.5MM
(
04P
)
SHIELD CWZPM48BN33
M-VOL. BN53 90M-YJ002920R 90M-YJ002920R CONN. 6P ANGLE CJP06GB99ZY
M-VOL. C527 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
M-VOL. C543 ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. C544 ns
p
00MOA106035Z0 ELECT CAP. 10UF 35V ROS HCEA1VR100T
M-VOL. C624 ns
p
00MOA22801620 ELECT CAP. 2200UF 16V CCEA1CH222E
M-VOL. CB52 90M-YP100330R 90M-YP100330R CONN. 7P ANGLE CJP07GF107ZY
M-VOL. CN56 ns
p
ns
p
CONN. STRAIGHT 3PIN CJP03GA19ZY
M-VOL. D624 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
M-VOL. J116 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J303 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J306 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J327 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J501 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J503 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J506 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J901 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. J902 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
M-VOL. JW52 ns
p
ns
p
CORD ST710388-5298T CWZPM48JW52
M-VOL. R527 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
M-VOL. R528 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
M-VOL. R539 ns
p
ns
p
RES. 56K OHM 1/5W J CRD20TJ563T
M-VOL. R540 ns
p
ns
p
RES. 56K OHM 1/5W J CRD20TJ563T
M-VOL. R548 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
M-VOL. R549 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
M-VOL. R621 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
M-VOL. VR53 90M-RB000070R 90M-RB000070R VAR. RES. VR MOTOR CVV9Y13B503Z
POWER SW PWB
(
CUP11954-5
)
P-SW C901 90M-DK100770R 90M-DK100770R CER. CAP. ! 0.0047UF 2.5KV KCKDKS472ME
P-SW JW96 ns
p
ns
p
CORD WIRE ASSY CWZPM48JW96
P-SW SW91 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
SPEAKER SW & LOUDNESS PWB
(
CUP11954-3
)
SPKR BK62 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
SPKR BK63 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
SPKR BN35 ns
p
ns
p
CORD WIRE ASSY CWB2B904400EN
SPKR BN54 90M-YJ002920R 90M-YJ002920R CONN. 6P ANGLE CJP06GB99ZY
SPKR C523 ns
p
ns
p
FILM CAP. 0.1UF 50V J HCQI1H104JZT
SPKR C524 ns
p
ns
p
FILM CAP. 0.1UF 50V J HCQI1H104JZT
SPKR C525 ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
SPKR C526 ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
SPKR J310 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
SPKR J311 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
SPKR R523 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
SPKR R524 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
SPKR R525 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
SPKR R526 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
SPKR SW52 90M-SP001240R 90M-SP001240R SW SPUL19X1M071 HSH2B017Z
SPKR SW61 90M-SP001240R 90M-SP001240R SW SPUL19X1M071 HSH2B017Z
SPKR SW62 90M-SP001240R 90M-SP001240R SW SPUL19X1M071 HSH2B017Z
SUB TRANSF. PWB
(
CUP11833-2
)
SUB-T C925 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
SUB-T C930 90M-DK100770R 90M-DK100770R CER. CAP. ! 0.0047UF 2.5KV KCKDKS472ME
SUB-T C931 ns
p
00MOA10802520 ELECT CAP. 1000UF 25V CCEA1EH102E
SUB-T C932 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
SUB-T C933 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
SUB-T C934 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
SUB-T C935 00MDF17104630 00MDF17104630 FILM CAP. ! 0.1UF 250V KD HCQE2E104KDE
SUB-T C936 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
SUB-T CN93 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
SUB-T CN94 ns
p
ns
p
CONN. MOLEX35328-02 CJP02GA89ZM
SUB-T CN96 ns
p
ns
p
CONN. MOLEX35328-02 CJP02GA89ZM
SUB-T D926 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
SUB-T D927 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
SUB-T D929 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
31
